FIG.820B FRONT DOOR LOCK (GL,GLX)

FIG.820B FRONT DOOR LOCK (GL,GLX)

No	No. Part	Description	Qty	Price Per Pcs	Remarks
1	82301-77M53-000	LATCH ASSY REAR DOOR RH	1	Rp253.500
2	82302-77M53-000	LATCH ASSY REAR DOOR RH	1	Rp253.500
3	09137-06028-000	SCREW (6X18)	6	Rp18.500
4	82610-61J00-000	STRIKER,DOOR LATCH	2	Rp19.500
5	09137-08014-000 SUB: 09137-08004-000	SCREW (8X18)	4	Rp23.000
6	82812-77M20-000	HANDLE,DOOR OUT	2	Rp96.000	PAINT TO MATCH
7	82813-77M20-000	CAP,DOOR OUT RH	1	Rp22.000	PAINT TO MATCH
8	82813-77M20-000	CAP,DOOR OUT LH	1	Rp22.000	PAINT TO MATCH
9	82811-77M20-000	FRAME,DOOR OUT RH	1	Rp71.500
10	82821-77M20-000	FRAME,DOOR OUT LH	1	Rp73.000
11	82814-77M00-000 SUB: 82814B77M00N000	PAD,DOOR OUT	2	Rp6.000
12	82815-77M00-000 SUB: 82815B77M00N000	CUSHION,SIDE DOOR OUT	2	Rp5.500
13	83110M74L10-GMN	HANDLE ASSY,DOOR INSIDE RH (CHROME/BEIGE)	1	Rp103.000
14	83130M74L10-GMN	HANDLE ASSY,DOOR INSIDE LH (CHROME/BEIGE)	1	Rp103.000
15	09132-05058-000	SCREW (5X12)	2	Rp14.000
16	09148-05031-000	NUT	2	Rp18.000
17	83271M50E00-000	CLIP	2	Rp6.500
18	09250M25L02-000	CAP (OD:33.5)	2	Rp5.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
