FIG. 74 COOLING UNIT

No	No. Part	Description	Qty	Price Per Pcs
1	74100-67L11-000 SUB: 74100B67L10N000	COOLING UNIT	1	Rp4.126.000
2	74111-67L10-000 SUB: 74111B67L10N000	•CASE, COOLER RH	1	Rp69.500
3	74112-67L10-000 SUB: 74112B67L10N000	•CASE, COOLER LH	1	Rp82.000
4	74116-67L10-000 SUB: 74116B67L10N000	•PACKING, UNIT OUT	1	Rp53.500
5	74170-82K11-000 SUB: 74170B82K11N000	•LEVER ASSY, VENT	1	Rp238.000
6	74192-67L10-000 SUB: 74192B67L10N000	•SCREW	3	Rp6.500
7	74191-67L10-000 SUB: 74191B67L10N000	•SCREW	21	Rp6.500
8	74210-67L10-000 SUB: 74210B67L10N000	•CASE, INTAKE	1	Rp87.500
9	74211-67L10-000 SUB: 74211B67L10N000	•CASE, BLOWER UPPER	1	Rp110.000
10	74212-67L10-000 SUB: 74212B67L10N000	•CASE, BLOWER LOWER	1	Rp86.500
11	74250-67L10-000 SUB: 74250B67L10N000	•FAN ASSY, BLOWER	1	Rp1.476.000
12	95411-67L10-000 SUB: 95411B67L10N000	•EVAPORATOR ASSY	1	Rp1.431.000
13	74166-67L10-000 SUB: 74166B67L10N000	••PLUG	1	Rp6.500
14	74811-67L10-000 SUB: 74811B67L10N000	••GROMMET	1	Rp26.000
15	95431-67L10-000 SUB: 95431B67L10N000	••VALVE, EXPANSION	1	Rp215.500
16	95432-67L10-000 SUB: 95432B67L10N000	••BOLT	2	Rp6.500
17	95541-67L10-000 SUB: 95541B67L10N000	••THERMISTOR & HOLDER ASSY	1	Rp103.000
18	95895B67L10N000	••O RING	1	-
19	95896-50G00-000 SUB: 95896B67L10N000	••O RING	1	Rp19.000
20	95462-67L10-000 SUB: 95462B67L10N000	•PACKING, DRAIN	1	Rp8.500
21	95462-68K00-000 SUB: 95462M68K00-000	•INSULATOR, DRAIN	1	Rp162.500
22	95463-67L10-000 SUB: 95463B67L10N000	•PACKING, TXV	1	Rp56.000
23	95861-58M00-000 SUB: 95861B58M00N000	•FILTER, AIR CONDITIONER	1	Rp169.500
24	09116-06115-000	BOLT	3	Rp14.500
25	09159-06081-000	NUT	2	Rp14.500
26	95481-67L10-000 SUB: 95481B67L10N000	HOSE, DRAIN	1	Rp21.000
