FIG.505B SEAT (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)

FIG.505B SEAT (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)
No No. Part Description Qty Price Per Pcs Remarks
1 45100-23K00-PRQ SEAT ASSY (BLACK) 1 Rp183.000
2 45148-23J00-000 _CUSHION, SEAT MOUNT 4 Rp4.500
3 45149-23K00-000 _CUSHION, BATTERY 1 Rp12.500
4 45241-23K00-000 BOLT, SEAT 2 Rp9.500
5 45289-23K10-000 GUARD, SEAT LOCK 1 Rp4.500
6 45288-12K00-000 GUIDE, SEAT LOCK CABLE 1 Rp4.500
7 45289-11F00-000
SUB: 45289B11F00N000		 PLATE, SEAT LOCK ASSY 1 Rp4.000
8 45220-04K30-000 BRACKET, STRIKER SUPPORT 1 Rp28.500
9 02142-0610A-000 SCREW 2 Rp3.500
10 45300-23K01-PRQ
SUB: 45300-23K00-PRQ		 SEAT ASSY, PILLION (BLACK) 1 Rp164.500
11 45148-20G80-000
SUB: 45148B20G80N000		 _CUSHION, SEAT MOUNT 2 Rp3.500
12 45290-23K00-000 _STRIKER, SEAT LOCK 1 Rp15.000
13 45380-23K01-PRQ
SUB: 45380-23K00-PRQ		 _BAND, PILLION SEAT GRIP(BLACK) 1 Rp12.000
14 09160-06012-000
SUB: 09160B06012N000		 _WASHER 2 Rp7.000
15 08316-1006A-000 _NUT 2 Rp2.000
16 95700-14820-000 LOCK ASSY, SEAT 1 Rp58.500
17 96510-23K00-000 TOOL ASSY 1 Rp42.500
18 01550-0612A-000 SCREW 2 Rp3.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
