FIG.483A UNDER COWLING (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)

FIG.483A UNDER COWLING (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)
No No. Part Description Qty Price Per Pcs Remarks
1-2 94491-23KA0-291 COWLING, UNDER RH (BLACK)FOR 291,YSF 1 Rp173.000 FOR 291,YSF
1-3 94491-23KA0-YNJ COWLING, UNDER RH (SILVER)FOR YNJ 1 Rp173.000 FOR YNJ
1-1 94491-23KA0-YZE COWLING, UNDER RH (RED)FOR GTA 1 Rp173.000 FOR GTA
2-1 94492-23KA0-YZE COWLING, UNDER LH (RED)FOR GTA 1 Rp173.000 FOR GTA
2-2 94492-23KA0-291 COWLING, UNDER LH (BLACK)FOR 291,YSF 1 Rp173.000 FOR 291,YSF
2-3 94492-23KA0-YNJ COWLING, UNDER LH (SILVER)FOR YNJ 1 Rp173.000 FOR YNJ
3 94493-23KA0-000 COWLING, UNDER CTR 1 Rp15.500
4 94570-23K00-000 BRACKET, SIDE COWL LWR RR 1 Rp7.000
5 94580-23KA0-000 BRACKET, UNDER COWL FR RH 1 Rp8.500
6 94436-23K00-000 CUSHION, UNDER COWLING RH 2 Rp4.000
7 09320-09016-000 CUSHION 2 Rp4.000
8 09139-06190-000
SUB: 09139B06190N000		 SCREW (6X20) 4 Rp7.000
9 09148-04019-000
SUB: 09148B04019N000		 NUT 3 Rp6.500
10 09409-06314-5PK
SUB: 09409-06314-000		 CLIP 1 Rp3.500
11 01550-0612A-000 BOLT 2 Rp3.500
12 01550B0612BN000 BOLT 1 Rp2.500
13 03541-0416B-000
SUB: 03541B0416BN000		 SCREW 3 Rp4.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
