FIG.445A FRAME COVER (GSX-S150MFL7 P12/GSX-S150MFL7 P12)

FIG.445A FRAME COVER (GSX-S150MFL7 P12/GSX-S150MFL7 P12)
No No. Part Description Qty Price Per Pcs Remarks
1-2 47111-23K00-YMC COVER, FRAME RH (SILVER)FOR YVU 1 Rp193.500 FOR YVU
1-1 47111-23K00-291 COVER, FRAME RH (BLACK)FOR GTA,YNJ,YSF 1 Rp194.500 FOR GTA,YNJ,YSF
2 47160-23KA0-000 BRACKET, FRAME COVER FR RH 1 Rp22.500
3-1 47211-23K00-291 COVER, FRAME LH (BLACK)FOR GTA,YNJ,YSF 1 Rp194.500 FOR GTA,YNJ,YSF
3-2 47211-23K00-YMC COVER, FRAME LH (SILVER)FOR YVU 1 Rp193.500 FOR YVU
4 44513-23K00-000 SCREW, FRAME COVER 6 Rp6.500
5 47260-23KA0-000 BRACKET, FRAME COVER FR LH 1 Rp22.500
6-3 47311-23K00-YNJ COVER, FRAME UPPER RH (SILVER)FOR YNJ 1 Rp219.500 FOR YNJ
6-4 47311-23K00-YSF COVER, FRAME UPPER RH (BLUE)FOR YSF 1 Rp192.500 FOR YSF
6-2 47311-23K00-291 COVER, FRAME UPPER RH (BLACK)FOR 291 1 Rp192.500 FOR 291
6-1 47311-23K00-YVU COVER, FRAME UPPER RH (BLACK)FOR GTA 1 Rp192.500 FOR GTA
7 47312-37H10-000
SUB: 47312-37H00-000		 CUSHION, FRAME COVER UPPER RR 2 Rp24.000
8-1 47411-23K00-YVU COVER, FRAME UPPER LH (BLACK)FOR GTA 1 Rp192.500 FOR GTA
8-2 47411-23K00-291 COVER, FRAME UPPER LH (BLACK)FOR 291 1 Rp192.500 FOR 291
8-3 47411-23K00-YNJ COVER, FRAME UPPER LH (SILVER)FOR YNJ 1 Rp219.500 FOR YNJ
8-4 47411-23K00-YSF COVER, FRAME UPPER LH (BLUE)FOR YSF 1 Rp192.500 FOR YSF
9-1 47511-23K00-YVU COVER, FRAME UPPER CTR (BLACK)FOR GTA 1 Rp88.500 FOR GTA
9-4 47511-23K00-YSF COVER, FRAME UPPER CTR (BLUE)FOR YSF 1 Rp88.500 FOR YSF
9-3 47511-23K00-YNJ COVER, FRAME UPPER CTR (SILVER)FOR YNJ 1 Rp88.500 FOR YNJ
9-2 47511-23K00-291 COVER, FRAME UPPER CTR (BLACK)FOR 291 1 Rp88.500 FOR 291
10 09136-06105-000 SCREW 2 Rp12.500
11 09148-04019-000
SUB: 09148B04019N000		 NUT 6 Rp6.500
12 09148-04019-000
SUB: 09148B04019N000		 NUT 2 Rp6.500
13 09148-05058-000
SUB: 09148B05058N000		 NUT 2 Rp15.000
14 09180-06283-000 SPACER 2 Rp13.000
15 48169-12JA0-000
SUB: 09320B08018N000		 CUSHION 2 Rp15.000
16 09320-09016-000 CUSHION 2 Rp4.000
17 09409-06314-5PK
SUB: 09409-06314-000		 CLIP 2 Rp3.500
18 09409-06314-5PK
SUB: 09409-06314-000		 CLIP 4 Rp3.500
19 01550-0612A-000 BOLT 1 Rp3.500
20 01550-0612A-000 BOLT 2 Rp3.500
21 03541-0412A-000
SUB: 03541B0412AN000		 SCREW 2 Rp3.500
22 03541-0412A-000
SUB: 03541B0412AN000		 SCREW 6 Rp3.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
