  5. FIG.467A HANDLE LEVER (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)

GSXR-150

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.355B HANDLE SWITCH (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.401A FRAME (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.401B FRAME (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.407A STAND (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.407B STAND (GSX-R150RFL7 P12/GSX-R150RFL7 P12)FIG.415A FOOTREST (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.415B FOOTREST (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.420A FUEL TANK (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.420B FUEL TANK (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.423A FUEL TANK COVER (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.423B FUEL TANK COVER (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.424A FUEL TANK SIDE COVER (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.445A FRAME COVER (GSX-S150MFL7 P12/GSX-S150MFL7 P12)FIG.445B FRAME COVER (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.451A HEADLAMP HOUSING (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.460A FRONT FENDER (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.460B FRONT FENDER (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.462A HANDLEBAR (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.462B HANDLEBAR (GSX-R150RFL7 P12/GSX-R150RFL7 P12)FIG.467A HANDLE LEVER (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.467B HANDLE LEVER (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.474A REAR FENDERFIG.481A COWLING BODY (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.483A UNDER COWLING (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.485A SIDE COWLING (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.496A LABELFIG.505A SEAT (GSX-S150MFL7 P12GSX-S150MFXL7 P12)FIG.505B SEAT (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.521A FRONT FORK DAMPERFIG.524A STEERING STEM (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.524B STEERING STEM (GSX-R150RFL7 P12)FIG.530A FRONT WHEELFIG.535A FRONT CALIPERFIG.536A FRONT BRAKE HOSE (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.536B FRONT BRAKE HOSE (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.537A FRONT MASTER CYLINDERFIG.541A REAR SWINGINGARMFIG.543A REAR CUSHION LEVERFIG.550A REAR WHEELFIG.555A REAR CALIPERFIG.558A REAR MASTER CYLINDERFIG.915A STRIPPING SET(GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.915B STRIPPING SET(GSX-S150MFL7 P12/GSX-S150MFXL7 P12)

FIG.467A HANDLE LEVER (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)

FIG.467A HANDLE LEVER (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)
No No. Part Description Qty Price Per Pcs Remarks
1 57110-23K01-000
SUB: 57110-23K00-000		 GRIP, THROTTLE 1 Rp28.500
2 57300-30H21-000 LEVER ASSY, BRAKE 1 Rp103.000
3 57431-30H20-000 _BOLT 1 Rp20.500
4 57421-30H10-000 _LEVER, BRAKE 1 Rp70.000
5 57433-30H10-000 _NUT 1 Rp8.500
6 57460-30H00-000 SWITCH ASSY, STOP 1 Rp36.500
7 57465-30H00-000 _SCREW 1 Rp6.500
8 57211-40J01-000
SUB: 57211-40J00-000		 GRIP, LH 1 Rp18.500
9 57500-25G80-000 LEVER ASSY, CLUTCH 1 Rp138.000
10 57621-23FB0-000 _LEVER, CLUTCH 1 Rp32.500
11 57431-23F10-000
SUB: 57431B23F10N000		 _BOLT, LEVER SET 1 Rp4.500
12 57513-23F10-000
SUB: 57513B23F10N000		 _NUT, LEVER SET 1 Rp4.000
13 57441-25G00-000
SUB: 57441B25G00N000		 _ADJUSTER, WIRE 1 Rp12.500
14 57442-25G00-000
SUB: 57442B25G00N000		 _NUT, LOCK 1 Rp9.000
15 01547-0625A-000
SUB: 01547B0625BN000		 _BOLT 2 Rp6.500
16 59671-09G30-000 _HOLDER 1 Rp14.500
17 57470-10JD0-000 _SWITCH ASSY, CLUTCH 1 Rp52.000
18 57661-25G00-000 COVER, CLUTCH LEVER 1 Rp11.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
