  5. FIG.460A FRONT FENDER (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)

GSXR-150

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.355B HANDLE SWITCH (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.401A FRAME (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.401B FRAME (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.407A STAND (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.407B STAND (GSX-R150RFL7 P12/GSX-R150RFL7 P12)FIG.415A FOOTREST (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.415B FOOTREST (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.420A FUEL TANK (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.420B FUEL TANK (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.423A FUEL TANK COVER (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.423B FUEL TANK COVER (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.424A FUEL TANK SIDE COVER (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.445A FRAME COVER (GSX-S150MFL7 P12/GSX-S150MFL7 P12)FIG.445B FRAME COVER (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.451A HEADLAMP HOUSING (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.460A FRONT FENDER (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.460B FRONT FENDER (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.462A HANDLEBAR (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.462B HANDLEBAR (GSX-R150RFL7 P12/GSX-R150RFL7 P12)FIG.467A HANDLE LEVER (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.467B HANDLE LEVER (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.474A REAR FENDERFIG.481A COWLING BODY (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.483A UNDER COWLING (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.485A SIDE COWLING (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.496A LABELFIG.505A SEAT (GSX-S150MFL7 P12GSX-S150MFXL7 P12)FIG.505B SEAT (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.521A FRONT FORK DAMPERFIG.524A STEERING STEM (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.524B STEERING STEM (GSX-R150RFL7 P12)FIG.530A FRONT WHEELFIG.535A FRONT CALIPERFIG.536A FRONT BRAKE HOSE (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)FIG.536B FRONT BRAKE HOSE (GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.537A FRONT MASTER CYLINDERFIG.541A REAR SWINGINGARMFIG.543A REAR CUSHION LEVERFIG.550A REAR WHEELFIG.555A REAR CALIPERFIG.558A REAR MASTER CYLINDERFIG.915A STRIPPING SET(GSX-R150RFL7 P12/GSX-R150RFXL7 P12)FIG.915B STRIPPING SET(GSX-S150MFL7 P12/GSX-S150MFXL7 P12)

FIG.460A FRONT FENDER (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)

FIG.460A FRONT FENDER (GSX-S150MFL7 P12/GSX-S150MFXL7 P12)
No No. Part Description Qty Price Per Pcs Remarks
1-1 53111-23K00-YVU FENDER, FRONT (BLACK)FOR GTA 1 Rp152.000 FOR GTA
1-2 53111-23K00-291 FENDER, FRONT (BLACK)FOR 291 1 Rp152.000 FOR 291
1-3 53111-23K00-YNJ FENDER, FRONT (SILVER)FOR YNJ 1 Rp165.000 FOR YNJ
1-4 53111-23K00-YSF FENDER, FRONT (BLUE)FOR YSF 1 Rp152.000 FOR YSF
2 47161-23J00-000 CHUSION, FRONT FENDER 4 Rp4.000
3 53121-23K00-000 SCREW, FRONT FENDER FR 2 Rp7.000
4 53122-23K00-000 SCREW, FRONT FENDER RR 2 Rp7.000
5 53275-34J00-000 SPACER, FRONT FENDER 4 Rp5.500
6 09160-06027-000
SUB: 09160-06060-000		 WASHER 4 Rp6.500
7 08316-1006A-000 NUT 2 Rp2.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
