AERIO, BALENO NEXT G

Preview Engine Transmission Electrical Suspension Body

< KEMBALI KE THUMBNAIL FIG.107 FRONT HOOD PANEL FIG.108 FRONT FENDER FIG.109 FRONT BODY PANEL FIG.110 FLOOR PANEL (TYPE 1:4DR)FIG.111 FLOOR PANEL (TYPE 2:4DR)FIG.112 FLOOR PANEL (TYPE 1:5DR)FIG.113 FLOOR PANEL (TYPE 2:5DR)FIG.114 SIDE BODY PANEL (4DR)FIG.115 SIDE BODY PANEL (5DR)FIG.116 ROOF PANEL (4DR)FIG.117 ROOF PANEL (5DR)FIG.118 FRONT BUMPER (TYPE 1)FIG.119 FRONT BUMPER (TYPE 2:4DR)FIG.120 FRONT BUMPER (TYPE 2:5DR)FIG.121 REAR BUMPER (TYPE 1:4DR)FIG.122 REAR BUMPER (TYPE 2:4DR)FIG.123 REAR BUMPER (TYPE 1:5DR)FIG.124 REAR BUMPER (TYPE 2:5DR)FIG.125 INSTRUMENT PANEL (TYPE 1)FIG.126 INSTRUMENT PANEL (TYPE 2)FIG.127 VENTILATOR (TYPE 1)FIG.128 VENTILATOR (TYPE 2)FIG.129 HEATER CONTROL (TYPE 1)FIG.130 HEATER CONTROL (TYPE 2)FIG.131 HEATER BLOWER (TYPE 1)FIG.132 HEATER BLOWER (TYPE 2)FIG.133 CONSOLE BOX (TYPE 1)FIG.134 CONSOLE BOX (TYPE 2)FIG.135 FLOOR CARPET (TYPE 1:4DR)FIG.136 FLOOR CARPET (TYPE 2:4DR)FIG.137 FLOOR CARPET (TYPE 1:5DR)FIG.138 FLOOR CARPET (TYPE 2:5DR)FIG.139 INTERRIOR TRIM (4DR)FIG.140 INTERRIOR TRIM (5DR)FIG.141 COVER CAP (4DR)FIG.142 COVER CAP (5DR)FIG.143 ROOF LINING (4DR)FIG.144 ROOF LINING (5DR)FIG.145 FUEL LID OPENER (4DR)FIG.146 FUEL LID OPENER (5DR)FIG.147 EMBLEM (4DR)FIG.148 EMBLEM (5DR)FIG.149 MOLDING (4DR)FIG.150 MOLDING (5DR)FIG.151 FRONT/BACK WINDOW (4DR)FIG.152 WINDSHIELD GLASS (5DR)FIG.153 SPLASH GUARD (4DR:TYPE 2)FIG.154 SPLASH GUARD (5DR:TYPE 2)FIG.155 FRONT DOOR PANEL FIG.156 FRONT DOOR REGULATOR FIG.157 FRONT DOOR LOCK FIG.158 4DR REAR DOOR PANEL FIG.159 4DR REAR DOOR REGULATOR FIG.160 DR REAR DOOR LOCK FIG.161 5DR REAR DOOR PANEL FIG.162 5DR REAR DOOR REGULATOR FIG.163 DR REAR DOOR LOCK FIG.164 TRUNK LID (4DR)FIG.165 TRUNK LID LOCK (4DR)FIG.166 BACK DOOR PANEL (5DR)FIG.167 BACK DOOR LOCK (5DR)FIG.168 MIRROR SURVISOR (TYPE 1)FIG.169 MIRROR SURVISOR (TYPE 2)FIG.170 TOOL FIG.171 FUEL TANK FIG.172 FRONT SEAT FIG.173 REAR SEAT (4DR)FIG.174 REAR SEAT (5DR)FIG.175 SEAT BELT FIG.176 PARCEL SHELF (5DR)FIG.177 AIR CONDITIONER

FIG.149 MOLDING (4DR)

FIG.149 MOLDING (4DR)

No	No. Part	Description	Qty	Price Per Pcs	Remarks
1	DISCONTINUE SUB: 78130-55G00-5PK	MOLDING, ROOF RH (BLACK)	1	-
2	DISCONTINUE SUB: 78140-55G00-5PK	MOLDING, ROOF RH (BLACK)	1	-
3	78170-79J10-000 SUB: 77543-65D10-000	CLIP, ROOF MOLDING	12	Rp52.500
4	DISCONTINUE SUB: 84761-50X50-000	FILM, JIG HOLE (140X190)	2	-	CUT AS REQUIRED
5	09250-10016-000 SUB: 09250B10016N000	CAP, REAR COMB OUTER	2	Rp14.000
6	77131-54G00-0CB	TAPE, CENTER PILLAR UPPER RH (BLACK)	1	-	BODY COLOR:ZA4,ZE9,Z2S,Z2T,Z2U,Z5K,ZXA,26U
7	77141-54G00-0CB	TAPE, CENTER PILLAR UPPER LH (BLACK)	1	-	BODY COLOR:ZA4,ZE9,Z2S,Z2T,Z2U,Z5K,ZXA,26U
8	DISCONTINUE SUB: 77211-55G00-5PK	GARNISH, REAR PILLAR OUTER RH (BLACK)	1	-
9	DISCONTINUE SUB: 77221-55G00-5PK	GARNISH, REAR PILLAR OUTER LH (BLACK)	1	-
10	DISCONTINUE SUB: 09409-11305-000	•CLIP	8	-
11	DISCONTINUE SUB: 77191M76F00-000	FILM, TRUNK SIDE CUSHION	2	-
12	DISCONTINUE SUB: 77191M76F00-000	FILM, REAR DOOR SIDE CUSHION	2	-
13	DISCONTINUE SUB: 77191M76F00-000	FILM, FRONT DOOR SIDE CUSHION	2	-
14	83919M82000-000	CAP, REAR WHEEL HOLE OUTER	2	Rp6.500
15	09250-15L03-000 SUB: 09250B15015N000	CAP, SIDE SILL OUTER	14	Rp5.500	TYPE 1
16	09250-15L03-000 SUB: 09250B15015N000	CAP, RR WHL HOLE OUTER NO.2	2	Rp5.500
17	09250-17001-000 SUB: 09250B17001N000	CAP, FRONT PILLAR OUTER	4	Rp6.500
18	09250-17001-000 SUB: 09250B17001N000	CAP, CENTER PILLAR OUTER	2	Rp6.500
19	77330-54G00-000 SUB: 77330B54G00N000	OUTLET, VENTILATOR	2	Rp43.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
