FIG.44A FRONT MASTER CYLINDER FD125XRM

FIG.44A FRONT MASTER CYLINDER FD125XRM
No No. Part Description Qty Price Per Pcs Remarks
1 61100-20G10-13L
SUB: 61100B20G10N000		 SWINGING ARM SET, REAR 1 Rp457.500
2 09319-10009-000
SUB: 09319-10009L000		 •BUSHING (10X23X35) 4 Rp18.000
3 61211-31C10-000
SUB: 61211B31C10N000		 SHAFT, REAR SWINGING ARM 1 Rp27.500
4 08310-00107-000 NUT 1 Rp15.000
5 61273-16H00-000
SUB: 61273B20G00N000		 BUFFER, CHAIN TOUCH DEFENSE 1 Rp20.000
6 DISCONTINUE
SUB: 64311B31C10N000		 TORQUE LINK, REAR 1 -
7 09140-08008-000 NUT 2 Rp10.500
8 DISCONTINUE
SUB: 04111-20208L000		 COTTER PIN 2 -
9 09111-08013-000
SUB: 09111B08013N000		 BOLT (8X26.5) 1 Rp5.500
10 08322M0108A-000
SUB: 08322M01083-000		 WASHER 2 Rp5.500
11 61410-20G30-000
SUB: 61410B20G00N000		 ADJUSTER, CHAIN 2 Rp34.500
12 08319-31067-000 NUT 2 Rp15.000
13 61421-16H00-000
SUB: 61421B20G00N000		 GUIDE, CHAIN ADJUSTER 2 Rp29.000
14 09160-12017-000
SUB: 09160B12017N000		 WASHER 2 Rp3.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
