FRONT RH SEAT (GX)

FRONT RH SEAT (GX)
No No. Part Description Qty Price Per Pcs Remarks
1 85001M66RC0-CMC SEAT ASSY, FR RH 1 Rp9.052.000
2 85103M66R24-000
SUB: 85103M66R20-000		 •FRAME ASSY, FR CUSH RH 1 Rp2.365.000
3 86652M74P50-000 ••CAP, FR ADJUSTER LOWER 2 Rp5.500
4 86653M74P50-000 ••CAP, FR ADJUSTER UPPER 1 Rp5.500
5 86652M74P50-000 ••CAP, FR ADJUSTER LOWER 2 Rp5.500
6 86653M74P50-000 ••CAP, FR ADJUSTER UPPER 1 Rp5.500
7 85160M66RA0-000 •PAD, FR CUSH RH 1 Rp523.000
8 85180M66RB0-CMC •TRIM, FR CUSH RH 1 Rp466.500
9 09387-19001-000
SUB: 09387B19001N000		 •RING 6 Rp9.000
10 85191M74L00-000 •CLAMP 1 Rp9.000
11 85211M62R00-5PK •KNOB, RCLNG RH (BLACK) 1 Rp35.000
12 85221M62R20-5PK •COVER, FR RCLNG OUTSIDE RH (BLACK) 1 Rp23.500
13 85222M68P00-5PK •COVER, FR RCLNG INSIDE LOWER RH (BLACK) 1 Rp22.000
14 85222M68P10-5PK •COVER, FR RCLNG INSIDE LOWER RH (BLACK) 1 Rp23.000
15 85241M68P10-5PK •COVER, FR RCLNG INSIDE RH (BLACK) 1 Rp29.000
16 85249M68P00-000 ••CLIP 1 Rp9.500
17 85295-58J01-000
SUB: 85295B58J01N000		 •BOLT, FR BACK FIX 1 Rp34.000
18 85305M66RA0-000 •BACK S/ASSY, FR RH 1 Rp1.659.000
19 85341M68P00-5PK •GUIDE, HEADRESTRAINT (BLACK) 1 Rp15.000
20 85380M66RA0-CMC •TRIM, FR BACK RH 1 Rp652.500
21 85840M68P00-5PK •GUIDE, HEADRESTRAINT 1 Rp31.000
22 09387-19001-000
SUB: 09387B19001N000		 •RING 12 Rp9.000
23 86401M68P70-PWC •HEADRESTRAINT ASSY, FR 1 Rp430.500
24 87286-58J10-000
SUB: 87286B58J10N000		 •BUSH, FR BACK FIX 1 Rp4.500
25 09132M04038-000 •SCREW 1 Rp5.500
26 36990-25G00-000
SUB: 09407-14403L000		 •CLAMP 1 Rp13.000
27 01550-1016A-000
SUB: 01550B1016AN000		 •BOLT 2 Rp5.500
28 03541-0410A-000 •SCREW 2 Rp11.000
29 09132M05065-000 •SCREW 2 Rp5.500
30 85213M62R20-5PK •LEVER, SEAT LIFTER RH (BLACK) 1 Rp66.500
31 85214M68PB0-5PK •CAP, LIFTER LEVER 1 Rp11.500
32 09119M08118-000
SUB: 09119M08111-000		 BOLT 4 Rp6.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
