REAR BUMPER (GX)

REAR BUMPER (GX)
No No. Part Description Qty Price Per Pcs Remarks
1 71811M66R30-799
SUB: 71811M66R10-799		 BUMPER,REAR(PRIMARY) 0 Rp1.189.000 PAINT TO MATCH
2 71821M66R00-000 HOLDER, RR BUMPER SIDE RH 1 Rp27.000
3 71822M66R00-000 HOLDER, RR BUMPER SIDE LH 1 Rp27.000
4 03541-0512A-000
SUB: 03541M0512A-000		 SCREW 4 Rp3.500
5 71831M66R00-5PK GARNISH, REAR BUMPER 1 Rp232.500
6 03541-0516A-000
SUB: 03541B0516AN000		 SCREW 3 Rp3.500
7 71870M66R10-5PK EXTENSION ASSY, RR BPR SIDE RH 1 Rp93.500
8 71880M66R10-5PK EXTENSION ASSY, RR BPR SIDE LH 1 Rp93.500
9 75463-74P10-000
SUB: 75463-71L00-000		 PAD, REAR BUMPER 1 Rp92.500
10 09136-05068-000 SCREW 2 Rp15.000
11 09409M08006-000
SUB: 09409M08L01-000		 CLIP 3 Rp5.000
12 09409M08006-000
SUB: 09409M08L01-000		 CLIP 4 Rp5.000
13 01551-0616C-000 BOLT 3 Rp14.500
14 08316-1005A-000
SUB: 08316B1005AN000		 NUT 6 Rp2.500
15 71851M62R00-000 PAD,REAR SKIRT 1 Rp23.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
