04111-2015A-000 |
PIN |
2 |
Rp4.500 |
| |
|
09440-17013-000
SUB: 09440B17013N000 |
SPRING |
1 |
Rp3.000 |
| |
|
08331-31149-000
SUB: 08331B31149N000 |
CIRCLIP |
2 |
Rp7.500 |
| |
|
25520-23K00-000 |
ARM, GEAR SHIFT LINK |
1 |
Rp30.000 |
| |
|
25525-23K00-000 |
ROD, GEAR SHIFT LINK |
1 |
Rp12.500 |
| |
|
25600-23K00-000 |
LEVER ASSY, GEAR SHIFTING |
1 |
Rp44.500 |
| |
|
25652-16H11-000
SUB: 25652B16H10N000 |
RUBBER, PEDAL |
1 |
Rp3.500 |
| |
|
25617-30H00-000 |
WASHER, GEAR SHIFT LINK ROD |
2 |
Rp3.500 |
| |
|
01500-0620A-000
SUB: 01500B0620AN000 |
BOLT |
1 |
Rp4.500 |
| |
|
25231-12K00-000 |
FORK, GEAR SHIFTING NO.3 |
1 |
Rp45.500 |
| |
|
09160-18043-000 |
WASHER (18X24X1) |
1 |
Rp4.500 |
| |
|
37720-12K12-000
SUB: 37720-12K10-000 |
BASE ASSY, GEAR SHIFT TERM |
1 |
Rp214.000 |
| |
|
37722-25G00-000
SUB: 37722B25G00N000 |
O RING (D:2.4,ID:26.2) |
1 |
Rp7.500 |
| |
|
36990-25G20-000 |
CLAMP, GEAR SHIFT SW LEAD |
1 |
Rp9.500 |
| |
|
09407-17403-000 |
CLAMP (L:154) |
2 |
Rp3.500 |
| |
|
07130-0520A-000
SUB: 07130B0520AN000 |
BOLT |
2 |
Rp5.500 |
| |
|
DISCONTINUE
SUB: 38490-65D20-000 |
|
1 |
- |
| |
|
25671-22J10-000 |
STOPPER, GEAR SHIFT |
1 |
Rp9.000 |
| |
|
25211-12K00-000 |
FORK, GEAR SHIFTING NO.1 |
2 |
Rp45.500 |
| |
|
25411-25G10-000
SUB: 25411B25G10N000 |
SHAFT, GEAR SHIFTING NO.1 |
1 |
Rp74.500 |
| |
|
25421-25G10-000
SUB: 25421B25G10N000 |
SHAFT, GEAR SHIFTING NO.2 |
1 |
Rp73.500 |
| |
|
25311-12K00-000 |
CAM, GEAR SHIFTING |
1 |
Rp109.500 |
| |
|
25312-12K00-000 |
SPACER, GEAR SHIFT CAM BRG |
1 |
Rp12.000 |
| |
|
25381-12K00-000 |
PLATE, GEAR SHIFT CAM |
1 |
Rp38.500 |
| |
|
07130-0620A-000 |
BOLT |
1 |
Rp16.500 |
| |
|
08110-69050-000
SUB: 08110B69050N000 |
BEARING |
1 |
Rp53.000 |
| |
|
25350-26D01-000
SUB: 25350B26D01N000 |
STOPPER, CAM |
1 |
Rp17.000 |
| |
|
25355-12K00-000 |
SPRING, STOPPER |
1 |
Rp4.500 |
| |
|
25357-22J00-000
SUB: 25357B22J00N000 |
BOLT, SHIFT CAM STOPPER |
1 |
Rp4.000 |
| |
|
25510-12K11-000
SUB: 25510-12K00-000 |
SHAFT, GEAR SHIFTING |
1 |
Rp64.500 |
| |
|
25512-12K01-000
SUB: 25512-12K00-000 |
PLATE, GEAR SHIFT CAM |
1 |
Rp47.500 |
| |
|
25518-12K00-000 |
SPRING, SHIFT SHAFT RETURN |
1 |
Rp6.500 |
| |
|
25519-25G00-000
SUB: 25519B25G00N000 |
WASHER (14X22X1) |
2 |
Rp4.500 |
| |
|
09283-14014-000
SUB: 09283B14014N000 |
SEAL (14X22X6) |
1 |
Rp9.000 |
| |
| 6 |
38496-56B00-000 |
•CONNECTOR |
1 |
Rp33.500 |
| |
| 10 |
09403-07307-5PK |
CLAMP, WASHER HOSE (BLACK) |
1 |
Rp18.500 |
| |
