FIG.103A (1-B-3) CYLINDER HEAD

FIG.103A (1-B-3) CYLINDER HEAD
No No. Part Description Qty Price Per Pcs Remarks
DISCONTINUE
SUB: 29628-57B00-000		 1 -
01547-0625A-000 BOLT 2 Rp6.500
09103-08555-000 BOLT (8X35) 3 Rp11.000
26585-57B01-000 1 Rp212.500
DISCONTINUE
SUB: 26510-52D10-000		 1 -
DISCONTINUE
SUB: 26552-57B00-000		 1 -
DISCONTINUE
SUB: 26538-57B00-000		 1 -
DISCONTINUE
SUB: 29627-77ED0-000		 1 -
DISCONTINUE
SUB: 26538-57B00-000		 1 -
09280-35009-000 O RING 2 Rp4.500
26589-57B00-000 1 Rp105.500
26591-57B00-000 1 Rp7.516.000
DISCONTINUE
SUB: 29973-57B00-000		 1 -
26592-57BT0-000 1 Rp5.541.000
29728-57B00-000 1 Rp70.000
DISCONTINUE
SUB: 29983-57B00-000		 1 -
DISCONTINUE
SUB: 26541-85FA0-000		 1 -
DISCONTINUE
SUB: 26523-85FA0-000		 1 -
13170-12K00-000 CLAMP 2 Rp9.500
09103-06165-000 BOLT (6X45) 2 Rp9.500
11141-12K01-000
SUB: 11141-12K00-000		 GASKET, CYLINDER HEAD 1 Rp31.000
09168-06004-000 GASKET (6.2X11X1.2) 1 Rp2.500
01550-0612A-000 BOLT 1 Rp3.500
09119-06120-000 BOLT (L:21.7) 1 Rp11.000
11117-12K00-000 BOLT, CYLINDER HEAD (L139) 4 Rp18.000
DISCONTINUE
SUB: 09160-08092-000		 WASHER (8.5X16X2.6) 4 -
01421-0625A-000
SUB: 01421B0625AN000		 STUD BOLT 2 Rp7.000
09482-00646-000 SPARK PLUG (MR8E-9) 1 Rp29.000
13111-12K01-000
SUB: 13111-12K00-000		 PIPE ASSY, INTAKE 1 Rp53.500
13121-12K00-000 PIPE ASSY, INTAKE NO.2 1 Rp9.500
13128-12K00-000 INSULATOR 1 Rp10.000
11100-12K00-000 HEAD ASSY, CYLINDER 1 Rp1.297.500
4 08316-1006A-000 NUT 3 Rp2.000
5 11191-27E70-000
SUB: 11191B27E70N000		 WASHER, HEAD COVER BOLT 2 Rp6.500
6 09103-06132-000
SUB: 09103B06132N000		 .BOLT (6X41) 12 Rp3.500
7 09206-08001-000
SUB: 09206B08001N000		 .PIN (6.2X8X11) 12 Rp5.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
