FIG.210A (1-C-5) TRANSMISSION (1)

FIG.210A (1-C-5) TRANSMISSION (1)
No No. Part Description Qty Price Per Pcs Remarks
24351-12K10-000 GEAR, 5TH DRIVEN (NT:23) 1 Rp113.500
07130-0610A-000
SUB: 07130B0610AN000		 BOLT 2 Rp5.500
27600-12K20-122
SUB: 27600-12K00-122		 CHAIN ASSY (RK 428KL0) 1 Rp332.500
27512-25G00-000 PLATE, ENGINE SPROCKET 1 Rp8.500
27511-23K10-000
SUB: 27511-23K00-000		 SPROCKET, ENGINE (NT:15) 1 Rp48.000
24751-05210-000
SUB: 24751B05210N000		 RETAINER, DRIVE SHAFT OIL SEAL 1 Rp8.500
08120-62040-000 BEARING 1 Rp45.000
08110-62020-000 BEARING 1 Rp52.000
24399-12K00-000 SEAL, DRIVE SHAFT OIL 1 Rp11.500
08211-20261-000 WASHER, THRUST 1 Rp8.500
08211-20241-000 WASHER 1 Rp5.000
08211-20241-000 WASHER 1 Rp5.000
08211-16251-000 WASHER 1 Rp5.500
08211-15251-000
SUB: 08211B15251N000		 WASHER 1 Rp4.500
09380-20009-000
SUB: 09380B20019N000		 CIRCLIP 1 Rp10.000
24361-12K10-000 GEAR, 6TH DRIVEN (NT:25) 1 Rp103.500
24121-12K10-000 COUNTERSHAFT (NT:13) 1 Rp185.000
24341-12K10-000 GEAR, 4TH DRIVEN (NT:28) 1 Rp99.000
24331-12K10-000 GEAR, 3RD DRIVEN (NT:31) 1 Rp98.000
24323-12K00-000 WASHER, 2ND DRIVEN GEAR LH 1 Rp9.500
24322-12K00-000 BUSH, 2ND DRIVEN GEAR 1 Rp5.500
24321-12K10-000 GEAR, 2ND DRIVEN (NT:29) 1 Rp93.000
24312-12K00-000 BUSH, 1ST DRIVEN GEAR 1 Rp33.000
24311-12K10-000 GEAR, 1ST DRIVEN (NT:38) 1 Rp105.500
24131-12K30-000 SHAFT, DRIVE 1 Rp174.000
08120-60020-000 BEARING 1 Rp22.500
09380-20009-000
SUB: 09380B20019N000		 CIRCLIP 1 Rp10.000
24261-12K10-000 GEAR, 6TH DRIVE (NT:27) 1 Rp90.000
24251-12K10-000 GEAR, 5TH DRIVE (NT:22) 1 Rp85.000
24231-12K10-000 GEAR, 3RD/4TH (NT:21/23) 1 Rp130.500
24221-12K10-000 GEAR, 2ND DRIVE (NT:15) 1 Rp66.500
8 08110-62040-000
SUB: 08110B62040N000		 BEARING, DRIVE SHAFT MIDDLE 1 Rp43.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
