| 1 |
64150-45H00-291
SUB: 64150B45H00N291 |
WHEEL, REAR (17X1.60) (BLACK) |
1 |
Rp1.173.000 |
| |
| 2 |
DISCONTINUE
SUB: 64210B16H20N291 |
PANEL, RR BRAKE ANCHOR (BLACK) |
1 |
- |
| |
| 3 |
54400-23820-000
SUB: 54400B23820N000 |
SHOE, SET REAR BRAKE |
1 |
Rp61.000 |
| |
| 4 |
09443-07025-000
SUB: 09443B07025N000 |
SPRING (L:35.8) |
2 |
Rp3.500 |
| |
| 5 |
64441-21D00-000
SUB: 64441B21D00N000 |
CAM, REAR BRAKE |
1 |
Rp34.500 |
| |
| 6 |
DISCONTINUE
SUB: 54492B35400N000 |
PLATE, BRAKE LINING INDICATOR |
1 |
- |
| |
| 7 |
64451-20G00-000
SUB: 64451B20G00N000 |
LEVER, REAR BRAKE CAM |
1 |
Rp9.500 |
| |
| 8 |
DISCONTINUE
SUB: 09103B06045N000 |
BOLT (6X32) |
1 |
- |
| |
| 9 |
09160-14054-000
SUB: 09160B14054N000 |
WASHER (14.5X22X1) |
1 |
Rp12.500 |
| |
| 10 |
09280-14011-000
SUB: 09280B14011N000 |
O RING (D:2.5,ID:13.8) |
1 |
Rp7.500 |
| |
| 11 |
08316-1006A-000 |
NUT |
1 |
Rp2.000 |
| |
| 12 |
64711-16H00-000
SUB: 64711B16H00N000 |
AXLE, REAR |
1 |
Rp24.500 |
| |
| 13 |
64741-07H00-000
SUB: 64741B07H00N000 |
SPACER, REAR AXLE RH |
1 |
Rp8.500 |
| |
| 14 |
08143-63017-001
SUB: 08143B63017N001 |
BEARING RH |
1 |
Rp25.000 |
RH | |
| 15 |
09180-12143-000
SUB: 09180-12143L000 |
SPACER (12.5X19X48) |
1 |
Rp9.000 |
| |
| 16 |
08143-62017-001
SUB: 08143B62017N001 |
BEARING LH |
1 |
Rp24.500 |
LH | |
| 17 |
08113-62017-000 |
BEARING LH |
1 |
Rp23.500 |
LH | |
| 18 |
64651-25G10-000
SUB: 64651B25G10N000 |
ABSORBER, REAR WHEEL HUB SHOCK |
1 |
Rp38.500 |
| |
| 19 |
64733-43000-000
SUB: 64733B43000N000 |
RETAINER, REAR SPROCKET DRUM |
1 |
Rp15.500 |
| |
| 20 |
64611-22J00-000
SUB: 64611B22J00N000 |
DRUM, REAR SPROCKET |
1 |
Rp87.000 |
| |
| 21 |
08113-62037-001
SUB: 08113B62037N001 |
BEARING |
1 |
Rp20.000 |
| |
| 22 |
09285-25L01-000
SUB: 09285B25L01N000 |
OIL SEAL (24X40X6) |
1 |
Rp7.000 |
| |
| 23 |
64721-20G00-000
SUB: 64721B20G00N000 |
SPACER, REAR SPROCKET DRUM |
1 |
Rp23.500 |
| |
| 24 |
08319-3112A-000
SUB: 08319B3112AN000 |
NUT |
1 |
Rp7.000 |
| |
| 25 |
64511-22J00-000
SUB: 64511B22J00N000 |
SPROCKET, REAR (NT:37) |
1 |
Rp112.000 |
| |
| 26 |
09105-08011-000
SUB: 09105-08011L000 |
BOLT (8X36) |
4 |
Rp6.500 |
| |
| 27 |
09160-12085-000
SUB: 09160B12085N000 |
WASHER (12.5X26X2.3) |
2 |
Rp6.500 |
| |
| 28 |
08319-3108A-000
SUB: 08319B3108AN000 |
NUT |
4 |
Rp4.000 |
| |
| 29 |
65110-38D20-000
SUB: 65110B38D20N000 |
TIRE, REAR (80/90-17M/C 44P) |
1 |
Rp297.000 |
| |
| 30 |
DISCONTINUE
SUB: 65200B45H70N000 |
TUBE ASSY, INNER |
1 |
- |
| |
| 31 |
43300-22J00-000
SUB: 43300B22J00N000 |
ROD ASSY, REAR BRAKE |
1 |
Rp36.000 |
| |
| 32 |
09440-09004-000
SUB: 09440-09004L000 |
.SPRING |
1 |
Rp12.500 |
| |
| 33 |
09209-11002-000 |
.PIN (11X18) |
1 |
Rp7.500 |
| |
| 34 |
09150-06010-000
SUB: 09150B06010N000 |
.NUT |
1 |
Rp4.500 |
| |
| 35 |
08322-0105A-000
SUB: 08322B0105AN000 |
.WASHER |
1 |
Rp3.000 |
| |
| 36 |
04111-2020A-000
SUB: 04111B2020AN000 |
.COTTER PIN |
1 |
Rp5.000 |
| |
