Satria F115 Young Star

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG. 30 FRAMEFIG. 31 STANDFIG. 32 FOOTRESTFIG. 33 FUEL TANKFIG. 34 FRAME COVERFIG. 35 FRONT LEG SHIELDFIG. 36 FRONT FENDERFIG. 37 HANDLEBARFIG. 38 HEADLAMP HOUSINGFIG. 39 HANDLE LEVERFIG. 40 REAR FENDERFIG. 41 LUGGAGE BOXFIG. 42 LABELFIG. 43 SEATFIG. 44 FRONT FORK DAMPERFIG. 45 STEERING STEMFIG. 46 FRONT WHEELFIG. 47 FRONT CALIPERFIG. 48 FRONT MASTER CYLINDERFIG. 49 REAR SWINGINGARMFIG. 50 CHAIN CASEFIG. 51 REAR WHEEL

FIG. 38 HEADLAMP HOUSING

FIG. 38 HEADLAMP HOUSING
No No. Part Description Qty Price Per Pcs Remarks
1 51811-32J00-YVU COVER, HANDLE FRONT (BLACK) 1 Rp228.500
2 09139-06190-000
SUB: 09139B06190N000		 BOLT (6X20) 2 Rp7.000
3 09320-09016-000 CUSHION 2 Rp4.000
4 DISCONTINUE
SUB: 51821-32J00-000		 CUSHION, HEADLAMP COVER 1 -
5 51850-32J00-000 BRACE , HEADLAMP 1 Rp79.000
6 51831-30H00-000 CUSHION, COWLING BRACE 2 Rp5.000
7 01550-0616B-000
SUB: 01550B0616BN000		 BOLT 2 Rp5.500
8 33652-35400-000
SUB: 33652B35400N000		 CUSHION, HEADLAMP & COVER 1 Rp7.000
9 DISCONTINUE
SUB: 48190-32J00-000		 PLATE, FRONT LICENSE 1 -
10 68281-22J01-ANN
SUB: 68281-22J00-ANN		 EMBLEM, FI (SILVER/GRAY) 1 Rp3.500
11 68641-22J11-000
SUB: 68641-22J10-000		 EMBLEM, S 1 Rp24.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
