| 1 |
12741-85FA0-000 |
SPROCKET, CAM SHAFT TIMING INTAKE RH |
1 |
Rp1.173.500 |
| |
| 2 |
12742-85FA0-000 |
SPROCKET, CAM SHAFT TIMING LH |
2 |
Rp1.978.000 |
| |
| 3 |
09103-12049-000 |
BOLT, PULLEY (12X25) |
3 |
Rp32.500 |
| |
| 4 |
09206-05001-000 |
PIN |
3 |
Rp11.500 |
| |
| 5 |
12745-85FA0-000 |
SPROCKET, IDLER NO.1 |
1 |
Rp1.144.000 |
| |
| 6 |
12747-85FA0-000 |
SHAFT, SPROCKET IDLER NO.1 |
1 |
Rp311.500 |
| |
| 7 |
12748-85FA0-000 |
WASHER, SPROCKET IDLER NO.1 |
1 |
Rp95.500 |
| |
| 8 |
07130-1035B-000 |
BOLT |
1 |
- |
| |
| 9 |
12750-85FA1-000
SUB: 12750-85FA0-000 |
SPROCKET, IDLER NO.2 |
1 |
Rp2.269.000 |
| |
| 10 |
12752-85FA0-000 |
SHAFT, SPROCKET IDLER NO.2 |
1 |
Rp430.500 |
| |
| 11 |
DISCONTINUE
SUB: 12753-85FA0-000 |
STUD BOLT |
1 |
- |
| |
| 12 |
08316-1010A-000
SUB: 08316-10103-000 |
NUT |
1 |
Rp3.500 |
| |
| 13 |
12761-85FA0-000 |
CHAIN, TIMING 1ST |
1 |
Rp2.376.500 |
| |
| 14 |
12771-85FA0-000 |
GUIDE, TIMING CHAIN NO.1 |
1 |
Rp208.000 |
| |
| 15 |
12811-85FA0-000 |
TENSIONER, TIMING CHAIN |
1 |
Rp698.500 |
| |
| 16 |
12812M73G10-000 |
SPACER, TIMING CHAIN TENSIONER |
1 |
Rp13.000 |
| |
| 17 |
09108-08255-000
SUB: 09108-08200-000 |
STUD BOLT |
1 |
Rp34.000 |
| |
| 18 |
08316-1008A-000
SUB: 08316B10083N000 |
NUT |
1 |
Rp3.500 |
| |
| 19 |
12772-85FA0-000 |
GUIDE, TIMING CHAIN NO.2 |
1 |
Rp186.000 |
| |
| 20 |
12762-85FA0-000 |
CHAIN, TIMING 2ND RH |
1 |
Rp826.000 |
| |
| 21 |
12773-85FA1-000
SUB: 12773-85FA0-000 |
GUIDE, TIMING CHAIN NO.3 |
1 |
Rp316.500 |
| |
| 22 |
DISCONTINUE
SUB: 01550B06123N000 |
BOLT |
2 |
- |
| |
| 23 |
12763-85FA0-000 |
CHAIN, TIMING 2ND LH |
1 |
Rp1.148.500 |
| |
| 24 |
12774-85FA1-000 |
GUIDE, TIMING CHAIN NO.4 |
1 |
Rp175.000 |
| |
| 25 |
01550-0616A-000
SUB: 01550-06163-000 |
BOLT |
2 |
Rp3.500 |
| |
| 26 |
12775-85FA0-000 |
GUIDE, TIMING CHAIN NO.5 |
1 |
Rp341.500 |
| |
| 27 |
12776-85FA0-000 |
BOLT |
4 |
Rp39.000 |
| |
| 28 |
DISCONTINUE
SUB: 12780-85FA0-000 |
JET, TIMING CHAIN |
1 |
- |
| |
| 29 |
DISCONTINUE
SUB: 01550B06123N000 |
BOLT |
1 |
- |
| |
| 30 |
12831-85FA7-000 |
ADJUSTER ASSY, TENSIONER |
1 |
Rp939.000 |
| |
| 31 |
01550-0620B-000
SUB: 01550-06203L000 |
BOLT |
2 |
Rp3.500 |
| |
| 32 |
12832-85FA0-000 |
ADJUSTER ASSY, TENSIONER NO.2 |
1 |
Rp1.139.000 |
| |
| 33 |
01550-0620B-000
SUB: 01550-06203L000 |
BOLT |
2 |
Rp3.500 |
| |
| 34 |
12833-85FA3-000 |
ADJUSTER ASSY, TENSIONER NO.3 |
1 |
Rp1.157.500 |
| |
| 35 |
01421M10353-000 |
STUD BOLT |
1 |
Rp19.000 |
| |
| 36 |
08316-1010A-000
SUB: 08316-10103-000 |
NUT |
1 |
Rp3.500 |
| |
| 37 |
07120-0640B-000 |
BOLT |
1 |
- |
| |
| 38 |
DISCONTINUE
SUB: 11381-67D01-000 |
COVER, TIMING CHAIN |
1 |
- |
| |
| 39 |
09206-08001-000
SUB: 09206B08001N000 |
PIN (6.2X8X11) |
2 |
Rp5.500 |
| |
| 40 |
01550-0630A-000
SUB: 01550-06303-000 |
BOLT |
25 |
Rp3.000 |
| |
| 41 |
12631-67D00-000 |
SPROCKET, CRANK SHAFT TIMING |
1 |
Rp956.500 |
| |
| 42 |
11215-67D00-000 |
PLUG, TIMING CHAIN COVER |
1 |
Rp69.000 |
| |
| 43 |
DISCONTINUE
SUB: 01550B06123N000 |
BOLT |
1 |
- |
| |
