SKYWAVE 125 (UW125SC)

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.1 COVER CYLINDER HEADFIG.2 CYLINDER HEADFIG.3 CYLINDERFIG.4 CRANKCASEFIG.5 CRANKCASE COVERFIG.6 CRANKSHAFTFIG.7 STARTER CLUTCHFIG.8 CAMSHAFT/VALVEFIG.9 CAMCHAINFIG.10 CARBURETORFIG.11 AIR FILTERFIG.12 CLEANER ASSYFIG.13 MUFFLERFIG.14 OIL PUMPFIG.15 COOLING FANFIG.16 2ND AIRFIG.17 TRANSMISSION (1)FIG.18 TRANSMISSION (2)FIG.19 KICK STARTER

FIG.11 AIR FILTER

FIG.11 AIR FILTER
No No. Part Description Qty Price Per Pcs Remarks
1 15411-16HA0-000 FILTER ASSY, MAIN AIR 1 Rp239.500
2 13168-13H00-000 HOSE 1 Rp76.000
3 13167-13H00-000 HOSE 1 Rp35.500
4 13670-13H00-000 NIPPLE 2 Rp133.000
5 09401-13102-A05
SUB: 09401-13102-000		 CLIP 3 Rp13.000
6 13169-13H00-000 COVER 1 Rp5.500
7 15412-13H00-000 SEAT 1 -
8 11345-13H10-000 CAP 1 Rp4.500
9 09401-06101-000 CLIP 1 Rp2.000
10 13166-13H00-000
SUB: 13166B13H00N000		 HOSE, MAIN AIR NO.1 1 Rp6.000
11 09364-06005-000
SUB: 09364B06005N000		 JOINT 1 Rp8.000
12 DISCONTINUE
SUB: 09359B35751N380		 HOSE, MAIN AIR NO.2 1 -
13 09403-08327-000
SUB: 09403B08327N000		 CLIP 2 Rp4.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
