FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.38 FRONT SUSPENSIONFIG.39 FRONT SUSPENSION FRAMEFIG.40 FRONT AXLEFIG.41 REAR SUSPENSIONFIG.42 REAR AXLEFIG.43 WHEEL AND TIREFIG.44 STEERING WHEELFIG.45 STEERING SHAFTFIG.46 STEERING GEARFIG.47 STEERING LINKFIG.48 PEDAL AND PEDAL BRACKETFIG.49 BRAKE MASTER CYLINDERFIG.50 BRAKE RESERVOIRFIG.51 BRAKE PIPINGFIG.52 FRONT WHEEL BRAKEFIG.53 REAR WHEEL BRAKEFIG.54 PARKING BRAKEFIG.55 SUSPENSION BRACKET

FIG.55 SUSPENSION BRACKET

FIG.55 SUSPENSION BRACKET
No No. Part Description Qty Price Per Pcs Remarks
1 59710-77500-000
SUB: 59710-77500L000		 CROSSMEMBER, FR FLOOR 1 Rp684.000
2 59120-77500-000
SUB: 59120-77500L000		 BRACKET, TENSION ROD RH 1 Rp300.000
3 59170-77500-000
SUB: 59170-77500L000		 BRACKET, TENSION ROD LH 1 Rp300.000
4 DISCONTINUE
SUB: 59130-77500L000		 BRACKET, FR SUSPENSION RH 1 -
5 DISCONTINUE
SUB: 59430-77500L000		 BRACKET, FR SUSPENSION LH 1 -
6 DISCONTINUE
SUB: 59230-77500L000		 HANGER, LEAF SPRING FR RH 1 -
7 DISCONTINUE
SUB: 59530-77500L000		 HANGER, LEAF SPRING FR LH 1 -
8 DISCONTINUE
SUB: 59260-77500L000		 HANGER, LEAF SPRING REAR 2 -
9 59216-77501-000 BRACKET, FUEL TANK RH 1 -
10 59737-77501-000 BRACKET, FUEL TANK LH 1 -
11 59743-77501-000 BRACKET, FUEL TANK REAR 1 -

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
