FUTURA SL415

Preview Engine Transmission Electrical Suspension Body

< KEMBALI KE THUMBNAIL FIG.38 FRONT SUSPENSION FIG.39 FRONT SUSPENSION FRAME FIG.40 FRONT AXLE FIG.41 REAR SUSPENSION FIG.42 REAR AXLE FIG.43 WHEEL AND TIRE FIG.44 STEERING WHEEL FIG.45 STEERING SHAFT FIG.46 STEERING GEAR FIG.47 STEERING LINK FIG.48 PEDAL AND PEDAL BRACKET FIG.49 BRAKE MASTER CYLINDER FIG.50 BRAKE RESERVOIR FIG.51 BRAKE PIPING FIG.52 FRONT WHEEL BRAKE FIG.53 REAR WHEEL BRAKE FIG.54 PARKING BRAKE FIG.55 SUSPENSION BRACKET

FIG.43 WHEEL AND TIRE

No	No. Part	Description	Qty	Price Per Pcs	Remarks
1-2	DISCONTINUE SUB: 43110-77500L000	TIRE (5.50-13-8PR)	2	-	W/PICK UP:FRONT
1-1	DISCONTINUE SUB: 43110-77510L000	TIRE (5.50-13-6PR)	2	-	W/PICK UP:FRONT
2	DISCONTINUE SUB: 43110-77500L000	TIRE (5.50-13-8PR)	3	-	W/PICK UP:REAR
3	43120-77500-000	TUBE (5.50-13)	5	-
4	43100-77520-000	TIRE (165R13-6PR)	5	-	W/MINI BUS
5	43210-77500-39M SUB: 43210-77500L39M	WHEEL (13X4 1/2-J)SILVER	5	Rp545.000
6	09140-12042-000	NUT	16	Rp21.000
7-4	DISCONTINUE SUB: 43234-78130-000	WEIGHT, WHEEL BALANCE (40G)	0	-
7-3	DISCONTINUE SUB: 43221-60C50-000	WEIGHT, WHEEL BALANCE (30G)	0	-
7-2	DISCONTINUE SUB: 43232-78130-000	WEIGHT, WHEEL BALANCE (20G)	0	-
7-1	DISCONTINUE SUB: 43231-78130-000	WEIGHT, WHEEL BALANCE (10G)	0	-
8	43250-77500-000	CAP, WHEEL CENTER	4	Rp257.500
9-1	DISCONTINUE SUB: 79161-77500L000	EMBLEM, AIR PRESSURE	1	-	W/PICK UP
9-2	DISCONTINUE SUB: 79161-77510-000	EMBLEM, AIR PRESSURE	1	-	W/MINI BUS
10	43210-77501-000 SUB: 43210B77501N000	WHEEL, AL (13X5J) (SILVER)	5	Rp1.152.000	FROM 2005-4
11	DISCONTINUE SUB: 43250B77520N27N	CAP, WHEEL CENTER	4	-	FROM 2008-4
12-2	43222-50J10-000	WEIGHT, WHEEL BALANCE (10G)	0	Rp44.000
12-9	43229-50J10-000	WEIGHT, WHEEL BALANCE (45G)	0	Rp66.500
12-8	DISCONTINUE SUB: 43228-50J10-000	WEIGHT, WHEEL BALANCE (40G)	0	-
12-7	DISCONTINUE SUB: 43227-50J10-000	WEIGHT, WHEEL BALANCE (35G)	0	-
12-6	DISCONTINUE SUB: 43226-50J10-000	WEIGHT, WHEEL BALANCE (30G)	0	-
12-5	DISCONTINUE SUB: 43225-50J10-000	WEIGHT, WHEEL BALANCE (25G)	0	-
12-4	DISCONTINUE SUB: 43224-50J10-000	WEIGHT, WHEEL BALANCE (20G)	0	-
12-3	43223-50J10-000	WEIGHT, WHEEL BALANCE (15G)	0	Rp47.000
12-1	DISCONTINUE SUB: 43221-50J10-000	WEIGHT, WHEEL BALANCE (5G)	0	-
13-1	43221-59J00-000	WEIGHT, WHEEL BALANCE (5G)	0	Rp32.000
13-2	43221-59J10-000	WEIGHT, WHEEL BALANCE (10G)	0	Rp40.000
13-3	43221-59J20-000	WEIGHT, WHEEL BALANCE (15G)	0	Rp42.000
13-4	43221-59J30-000	WEIGHT, WHEEL BALANCE (20G)	0	Rp44.000
13-5	43221-59J40-000	WEIGHT, WHEEL BALANCE (25G)	0	Rp47.000
13-6	43221-59J50-000	WEIGHT, WHEEL BALANCE (30G)	0	Rp49.500
13-7	43221-59J60-000	WEIGHT, WHEEL BALANCE (35G)	0	Rp52.500
13-8	43221-59J70-000	WEIGHT, WHEEL BALANCE (40G)	0	Rp54.500
13-9	43221-59J80-000	WEIGHT, WHEEL BALANCE (45G)	0	Rp57.000
13-10	43221-59J90-000	WEIGHT, WHEEL BALANCE (50G)	0	Rp60.000
