FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.38 FRONT SUSPENSIONFIG.39 FRONT SUSPENSION FRAMEFIG.40 FRONT AXLEFIG.41 REAR SUSPENSIONFIG.42 REAR AXLEFIG.43 WHEEL AND TIREFIG.44 STEERING WHEELFIG.45 STEERING SHAFTFIG.46 STEERING GEARFIG.47 STEERING LINKFIG.48 PEDAL AND PEDAL BRACKETFIG.49 BRAKE MASTER CYLINDERFIG.50 BRAKE RESERVOIRFIG.51 BRAKE PIPINGFIG.52 FRONT WHEEL BRAKEFIG.53 REAR WHEEL BRAKEFIG.54 PARKING BRAKEFIG.55 SUSPENSION BRACKET

FIG.54 PARKING BRAKE

FIG.54 PARKING BRAKE
No No. Part Description Qty Price Per Pcs Remarks
1 54100-77500-000 LEVER ASSY, PARKING BRAKE 1 Rp934.500
2 01550-0820A-000
SUB: 01550B0820AN000		 BOLT 2 Rp5.500
3 54410-77500-000
SUB: 54410-77500L000		 CABLE, NO.1 1 Rp112.500
4 09383-12001-000 E RING 1 Rp12.500
5 09200-08049-000 PIN 1 Rp14.500
6 04111-2515A-000
SUB: 04111B2515AN000		 COTTER PIN 1 Rp8.500
7 DISCONTINUE
SUB: 09308-11006L000		 GROMMET 1 -
8 54482-79000-000 STOPPER, CABLE 1 Rp41.000
9 54430-77501-000
SUB: 54430B77501N000		 CABLE ASSY, NO.2 1 Rp238.500
10 09443-12038-000 SPRING 1 Rp154.500
11 53771-85000-000 CLIP, CABLE 2 Rp20.500
12 DISCONTINUE
SUB: 54491-77500-000		 BAND, CABLE 2 -
13 02162-0610A-000 BOLT 4 Rp5.000
14 09160-08054-000 WASHER (8.5X20X1.6) 4 Rp10.500
15 08310-0008A-000
SUB: 08310M0008A-000		 NUT 2 Rp12.500
16 09403-06405-000 CLAMP 4 Rp18.500
17 09132-06006-000 SCREW 4 Rp18.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
