FIG.48 PEDAL AND PEDAL BRACKET

FIG.48 PEDAL AND PEDAL BRACKET
No No. Part Description Qty Price Per Pcs Remarks
1 49400-77500-000 PEDAL, ACCELERATOR 1 Rp652.000
2 08316-1008A-000
SUB: 08316B1008AN000		 NUT 2 Rp3.500
3 49451-70D00-000 COVER, ACCELERATOR PEDAL 1 Rp70.000
4 02162-0512A-000 BOLT 2 Rp11.500
5 09251-09002-000 CAP, STOPPER BOLT 1 Rp22.000
6 09100M06150-000 BOLT (6X31) 1 Rp4.500
7 08310-0006A-000
SUB: 08310B0006AN000		 NUT 1 Rp2.500
8 49610-77500-000 PEDAL, BRAKE 1 Rp579.000
9 09306M13004-000
SUB: 09307M13005-000		 BUSH, BRAKE PEDAL BOSS 2 Rp11.500
10 49751M58J00-000 PAD, PEDAL 1 Rp9.500
11 49621-77500-000 SPACER 1 Rp48.000
12 09448-30011-000 SPRING 1 Rp30.500
13 08316-1010A-000
SUB: 08316B1010AN000		 NUT 1 Rp3.500
14 49810-77500-000 PEDAL, CLUTCH 1 Rp543.000
15 09306M13004-000
SUB: 09307M13005-000		 BUSH, CLUTCH PEDAL BOSS 2 Rp11.500
16 49751M58J00-000 PAD, PEDAL 1 Rp9.500
17 49621-77500-000 SPACER 1 Rp48.000
18 49817-77500-000 SPRING 1 Rp202.000
19 49710-77502-000 BRACKET, PEDAL 1 Rp2.369.000
20 49730-77500-000 STAY, PEDAL BRACKET NO.1 1 Rp293.000
21 49740-77501-000
SUB: 49740B77501N000		 STAY, PEDAL BRACKET NO.2 1 Rp56.500
22 49750-77501-000
SUB: 49750B77501N000		 STAY, PEDAL BRACKET NO.3 1 Rp81.000
23 09100-10009-000 BOLT (10X96) 1 Rp23.000
24 08322-0110B-000
SUB: 08322B0110BN000		 WASHER 1 Rp4.500
25 01550-0812A-000
SUB: 01550B0812AN000		 BOLT 10 Rp3.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
