FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.38 FRONT SUSPENSIONFIG.39 FRONT SUSPENSION FRAMEFIG.40 FRONT AXLEFIG.41 REAR SUSPENSIONFIG.42 REAR AXLEFIG.43 WHEEL AND TIREFIG.44 STEERING WHEELFIG.45 STEERING SHAFTFIG.46 STEERING GEARFIG.47 STEERING LINKFIG.48 PEDAL AND PEDAL BRACKETFIG.49 BRAKE MASTER CYLINDERFIG.50 BRAKE RESERVOIRFIG.51 BRAKE PIPINGFIG.52 FRONT WHEEL BRAKEFIG.53 REAR WHEEL BRAKEFIG.54 PARKING BRAKEFIG.55 SUSPENSION BRACKET

FIG.46 STEERING GEAR

FIG.46 STEERING GEAR
No No. Part Description Qty Price Per Pcs Remarks
1 48500-77500-000 BOX ASSY, STEERING GEAR 1 Rp7.569.500
2 DISCONTINUE
SUB: 48501-77500-000		 .CASE, STEERING GEAR 1 -
3 DISCONTINUE
SUB: 48550-77500-000		 .PINION, STEERING 1 -
4 48557-85060-000 .RING, PINION BEARING SNAP 1 Rp45.000
5 48558-85060-000 .RING, PINION BEARING 1 Rp34.000
6 48556-85060-000 .SEAL, GEAR CASE OIL 1 Rp43.500
7 48534-77500-000 .PLUNGER, STEERING RACK 1 Rp177.500
8 48539-69D00-000 .SPRING, RACK PLUNGER 1 Rp35.500
9 48536-85060-000 .NUT, RACK DAMPER SCREW 1 Rp64.000
10 48535-85060-000 .SCREW, RACK DAMPER 1 Rp87.500
11 48581-85060-000 .CAP, STEERING PINION 1 Rp46.000
12 DISCONTINUE
SUB: 48531-77500-000		 .RACK, STEERING 1 -
13 48571-77500-000 .BOOT, STEERING RACK NO.1 1 Rp342.500
14 48572-77500-000 .BOOT, STEERING RACK NO.2 1 Rp342.500
15 48593-85060-000 .WIRE, RACK BOOT 2 Rp32.000
16 09401-20403-XC0 .CLIP, RACK BOOT NO.1 1 Rp35.000
17 48595-85060-000 .CLIP, RACK BOOT NO.2 1 Rp34.000
18 48591-85060-000 .YOKE, STEERING RACK 1 Rp158.000
19 48592-85060-000 .NUT, RACK YOKE 1 Rp48.500
20 09160-20075-000 .WASHER, RACK STOPPER NO.1 (20X30X2) 1 Rp17.500
21 48597-85060-000 .WASHER, RACK STOPPER NO.2 1 Rp106.000
22 48598-85060-000 .CIRCLIP, RACK STOPPER 1 Rp26.500
23 09118-12002-000 BOLT (12X35) 2 Rp34.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
