FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.38 FRONT SUSPENSIONFIG.39 FRONT SUSPENSION FRAMEFIG.40 FRONT AXLEFIG.41 REAR SUSPENSIONFIG.42 REAR AXLEFIG.43 WHEEL AND TIREFIG.44 STEERING WHEELFIG.45 STEERING SHAFTFIG.46 STEERING GEARFIG.47 STEERING LINKFIG.48 PEDAL AND PEDAL BRACKETFIG.49 BRAKE MASTER CYLINDERFIG.50 BRAKE RESERVOIRFIG.51 BRAKE PIPINGFIG.52 FRONT WHEEL BRAKEFIG.53 REAR WHEEL BRAKEFIG.54 PARKING BRAKEFIG.55 SUSPENSION BRACKET

FIG.51 BRAKE PIPING

FIG.51 BRAKE PIPING
No No. Part Description Qty Price Per Pcs Remarks
1 51410-77500-000
SUB: 51410-77500L000		 PIPE, MA PRIMARY TO VALVE 1 Rp96.500
2 DISCONTINUE
SUB: 51420-77500L000		 PIPE, VALVE TO FR BK HOSE 1 -
3 51430-77501-000 PIPE, VALVE TO FL BK HOSE 1 Rp40.000
4 51460-77501-000 PIPE, VALVE TO RR BK HOSE 1 Rp87.000
5 DISCONTINUE
SUB: 51470-77500L000		 PIPE, RR BK HOSE TO R BK ASSY 1 -
6 51480-77500-000
SUB: 51480-77500L000		 PIPE, R BK ASSY TO L BK ASSY 1 Rp44.500
7 51510-77500-000
SUB: 51510-77500L000		 PIPE, MA SECONDARY TO VALVE 1 Rp87.000
8 51751-85000-000 GROMMET, BRAKE PIPE 1 Rp33.500
9 51560-77510-000
SUB: 51560B77510N000		 HOSE, FLEXIBLE 1 Rp136.500
10 51540-77500-000
SUB: 51540B77500N000		 HOSE, FLEXIBLE 2 Rp310.500
11 09161-10009-000 GASKET, FLEXIBLE HOSE 4 Rp12.500
12 09360-10026-000 BOLT, CALIPER & HOSE 2 Rp25.000
13 09383M13004-000
SUB: 09383-13003-000		 E RING, BRAKE FLEXIBLE HOSE 6 Rp7.000
14-1 51960-77510-000 VALVE ASSY, B.P. 1 - W/MINI BUS
14-2 51960-77520-000 VALVE ASSY, B.P. 1 Rp2.447.000 W/PICK UP
15 01550-0635A-000
SUB: 01550B0635AN000		 BOLT 2 Rp3.000
16 09403-06401-000 CLAMP, PIPE NO.1 10 Rp16.500
17 09403-06401-000 CLAMP, PIPE NO.2 2 Rp16.500
18 DISCONTINUE
SUB: 09403-06404-000		 CLAMP, PIPE NO.3 1 -
19 09403-07312-000 CLAMP, PIPE NO.4 3 Rp16.000
20 01570-0612A-000 BOLT 1 Rp14.500
21 09132-06006-000 SCREW 15 Rp18.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
