FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.38 FRONT SUSPENSIONFIG.39 FRONT SUSPENSION FRAMEFIG.40 FRONT AXLEFIG.41 REAR SUSPENSIONFIG.42 REAR AXLEFIG.43 WHEEL AND TIREFIG.44 STEERING WHEELFIG.45 STEERING SHAFTFIG.46 STEERING GEARFIG.47 STEERING LINKFIG.48 PEDAL AND PEDAL BRACKETFIG.49 BRAKE MASTER CYLINDERFIG.50 BRAKE RESERVOIRFIG.51 BRAKE PIPINGFIG.52 FRONT WHEEL BRAKEFIG.53 REAR WHEEL BRAKEFIG.54 PARKING BRAKEFIG.55 SUSPENSION BRACKET

FIG.47 STEERING LINK

FIG.47 STEERING LINK
No No. Part Description Qty Price Per Pcs Remarks
1 48700-77812-000 ARM SET, INTERMEDIATE 1 Rp1.596.500
2 48750-85001-000 .BUSH 1 Rp325.500
3 48771-85001-000 COVER, DUST 1 Rp34.000
4 09160-20057-000 WASHER (20.2X42X2.3) 1 Rp16.500
5 08310-0018A-000 NUT 1 Rp18.500
6 09162-1802-000 LOCK WASHER 1 -
7 48900-77500-000 ROD ASSY, DRAG 1 Rp1.266.500
8 48800-82810-000
SUB: 48819-82000-000		 .BOOT ASSY 1 Rp191.000
9 09401-23402-000 .CLIP 1 Rp20.500
10 09101-12009-000 BOLT (12X49) 1 Rp32.000
11 08314-40123-000
SUB: 08314-40123L000		 NUT 2 Rp4.500
12 04111-3020A-000
SUB: 04111B3020AN000		 COTTER PIN 2 Rp2.500
13 48810-79000-000 END, TIE ROD RH 2 Rp424.000
14 48820-79000-000 END, TIE ROD LH 2 Rp424.000
15 48800-82810-000
SUB: 48819-82000-000		 .BOOT ASSY 4 Rp191.000
16 09401-23402-000 .CLIP 4 Rp20.500
17 48830-77500-000
SUB: 48830-77500L000		 TIE ROD, STEERING 2 Rp90.000
18 08310-0014A-000 NUT 2 Rp19.500
19 09140-14027-000 NUT 2 Rp21.500
20 08314-40123-000
SUB: 08314-40123L000		 NUT 4 Rp4.500
21 04111-3020A-000
SUB: 04111B3020AN000		 COTTER PIN 4 Rp2.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
