FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.38 FRONT SUSPENSIONFIG.39 FRONT SUSPENSION FRAMEFIG.40 FRONT AXLEFIG.41 REAR SUSPENSIONFIG.42 REAR AXLEFIG.43 WHEEL AND TIREFIG.44 STEERING WHEELFIG.45 STEERING SHAFTFIG.46 STEERING GEARFIG.47 STEERING LINKFIG.48 PEDAL AND PEDAL BRACKETFIG.49 BRAKE MASTER CYLINDERFIG.50 BRAKE RESERVOIRFIG.51 BRAKE PIPINGFIG.52 FRONT WHEEL BRAKEFIG.53 REAR WHEEL BRAKEFIG.54 PARKING BRAKEFIG.55 SUSPENSION BRACKET

FIG.50 BRAKE RESERVOIR

FIG.50 BRAKE RESERVOIR
No No. Part Description Qty Price Per Pcs Remarks
1 51200-77501-000
SUB: 51200B77501N000		 RESERVOIR ASSY, BRAKE MASTER 1 Rp159.000
2 51220-77500-000
SUB: 51220-77501-000		 .CAP, RESERVOIR 1 Rp70.500
3 DISCONTINUE
SUB: 51211-77500-000		 .FLOAT, RESERVOIR 1 -
4 DISCONTINUE
SUB: 02112-7616A-000		 SCREW 2 -
5 51241-85X50-000 HOSE, RESERVOIR 1 Rp256.500 L:300->190
6 DISCONTINUE
SUB: 09400-15303-000		 CLAMP 2 -
7 51010-77510-000 HOSE, VACUUM MASTER 1 Rp308.000
8 09403-18405-000 CLAMP 1 Rp46.500
9 09401-15404-000 CLAMP 4 Rp14.500
10 01550-0612B-000 BOLT 1 Rp16.500
11 51380-77500-000
SUB: 51380-77500L000		 PIPE, VACUUM MASTER 1 Rp45.500
12 51252-85400-000 CLAMP, PIPE MASTER 1 Rp42.500
13 09132-06006-000 SCREW 2 Rp18.000
14 09308-09016-000
SUB: 09308-09016L000		 GROMMET 1 Rp6.500
15 51020-77510-000 HOSE, VACUUM CENTER 1 Rp217.000
16 51022-77510-000 BRACKET, VACUUM HOSE 1 -
17 01550-0812A-000
SUB: 01550B0812AN000		 BOLT, VACUUM HOSE BRACKET 1 Rp3.500
18 09407-17402-000
SUB: 09407-14408-000		 CLAMP 2 Rp39.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
