FIG.41 REAR SUSPENSION

No	No. Part	Description	Qty	Price Per Pcs	Remarks
1-2	41310-77550-000 SUB: 41310-77550L000	SPRING ASSY, REAR RH	1	Rp1.605.500	W/MINI BUS
1-1	41310-77550-000 SUB: 41310-77550L000	SPRING ASSY, REAR RH	1	Rp1.605.500	W/PICK UP
2-1	41310-77560-000 SUB: 41310-77560L000	SPRING ASSY, REAR LH	1	Rp1.605.500	W/PICK UP
2-2	41310-77560-000 SUB: 41310-77560L000	SPRING ASSY, REAR LH	1	Rp1.605.500	W/MINI BUS
3-1	41118-77500-000 SUB: 41118B77500N000	.SILENCER, SPRING	4	Rp11.500	W/PICK UP
3-2	41118-77500-000 SUB: 41118B77500N000	.SILENCER, SPRING	8	Rp11.500	W/MINI BUS
4	41118-77500-000 SUB: 41118B77510N000	.SILENCER, SPRING	4	Rp11.500	W/MINI BUS
5	41331-77500-000	BUSHING, FRONT	2	Rp434.500
6	09103M12057-000	BOLT (12X88)	2	Rp20.500
7	DISCONTINUE SUB: 08321-01123L000	LOCK WASHER	2	-
8	08310-0012A-000 SUB: 08310-00123L000	NUT	2	Rp17.500
9	41333-77500-000 SUB: 41333B77500N000	BUSHING, REAR LOWER	4	Rp11.000
10	09305-13007-000	BUSHING, REAR UPPER	4	Rp31.000
11	41462-77500-000	PLATE, INNER	2	Rp100.000
12	DISCONTINUE SUB: 41461-77500L000	PLATE, OUTER	2	-
13	41463-77510-000	PIN, LOWER	2	Rp74.000
14	41463-77500-000	PIN, UPPER	2	Rp82.000
15	08321-0110A-000	LOCK WASHER	4	Rp14.000
16	08310-0010A-000 SUB: 08310B0010AN000	NUT	4	Rp3.500
17	41430-77500-000	SEAT, REAR SPRING RH	1	Rp399.500
18	41440-77500-000	SEAT, REAR SPRING LH	1	Rp399.500
19-1	42150-77500-000	BUMPER, REAR SPRING	2	Rp376.000	W/PICK UP
19-2	42150-77550-000	BUMPER, REAR SPRING	2	Rp665.500	W/MINI BUS
20	41411-77500-000 SUB: 41411-77500L000	U BOLT	4	Rp40.500
21	DISCONTINUE SUB: 08321-01123L000	LOCK WASHER	8	-
22	08310-0012A-000 SUB: 08310-00123L000	NUT	8	Rp17.500
23-1	41700-77500-000 SUB: 41700-77500L000	ABSORBER ASSY, REAR SHOCK	2	Rp207.000	W/PICK UP
23-2	41700-77560-000 SUB: 41700-77560L000	ABSORBER ASSY, REAR SHOCK	2	Rp238.500	W/MINI BUS
24	41781-52010-000	.BUSHING	4	Rp28.500
25	08321-0110A-000	LOCK WASHER	2	Rp14.000
26	08310-0010A-000 SUB: 08310B0010AN000	NUT	2	Rp3.500
27	08322-0116A-000 SUB: 08322B0116AN000	WASHER	2	Rp6.500
28	09160-12073-000	WASHER (12.5X32X2.3)	2	Rp16.000
29	08310-0012A-000 SUB: 08310-00123L000	NUT	2	Rp17.500
