FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.38 FRONT SUSPENSIONFIG.39 FRONT SUSPENSION FRAMEFIG.40 FRONT AXLEFIG.41 REAR SUSPENSIONFIG.42 REAR AXLEFIG.43 WHEEL AND TIREFIG.44 STEERING WHEELFIG.45 STEERING SHAFTFIG.46 STEERING GEARFIG.47 STEERING LINKFIG.48 PEDAL AND PEDAL BRACKETFIG.49 BRAKE MASTER CYLINDERFIG.50 BRAKE RESERVOIRFIG.51 BRAKE PIPINGFIG.52 FRONT WHEEL BRAKEFIG.53 REAR WHEEL BRAKEFIG.54 PARKING BRAKEFIG.55 SUSPENSION BRACKET

FIG.49 BRAKE MASTER CYLINDER

FIG.49 BRAKE MASTER CYLINDER
No No. Part Description Qty Price Per Pcs Remarks
1 51100-77510-000
SUB: 51100B77510N000		 CYLINDER ASSY, BRAKE MASTER 1 Rp1.189.500
2 51100-77831-000
SUB: 51100-77831L000		 .PISTON SET, BRAKE MASTER 1 Rp477.500
3 DISCONTINUE
SUB: 51141-77500L000		 .UNION 1 -
4 DISCONTINUE
SUB: 51142-77500-000		 .BAND ASSY, RESERVOIR 1 -
5 51313-61J00-000 NUT, BOOSTER 2 Rp6.500
6 DISCONTINUE
SUB: 51314-61J00-000		 WASHER, BOOSTER 2 -
7 51300-77520-000
SUB: 51300B77520N000		 BOOSTER ASSY, BRAKE MASTER 1 Rp1.090.500
8 09200M10021-000 PIN 1 Rp7.000
9 04111-2520A-000 COTTER PIN 1 Rp9.000
10 09159-08127-000
SUB: 09159-08135-000		 NUT 4 Rp11.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
