FIG.53 REAR WHEEL BRAKE

No	No. Part	Description	Qty	Price Per Pcs
1	53110-77500-000 SUB: 53110-77500L000	PLATE, BACKING RH	1	Rp209.000
2	53120-77500-000 SUB: 53120-77500L000	PLATE, BACKING LH	1	Rp209.000
3	DISCONTINUE SUB: 01500-0612A-000	BOLT, WHEEL CYLINDER	4	-
4	DISCONTINUE SUB: 08321M0106A-000	LOCK WASHER, WHEEL CYLINDER	4	-
5	53200-77501-000 SUB: 53200B77500N000	SHOE, BRAKE	4	Rp161.000
6	53231-79240-000 SUB: 53231-79240L000	SPRING, SHOE RETURN	4	Rp26.000
7	52241-85400-000 SUB: 52241-85400L000	PIN, SHOE HOLD DOWN	4	Rp7.500
8	53243-60A00-000 SUB: 53243-60A00L000	SPRING, SHOE HOLD DOWN	4	Rp12.500
9	53331-60A00-000 SUB: 53331-60A00L000	SPRING, SHOE RETURN UPPER	2	Rp35.500
10	53401-77500-000 SUB: 53401-77500L000	CYLINDER ASSY, REAR WHEEL RH	1	Rp369.000
11	53402-77500-000 SUB: 53402-77500L000	CYLINDER ASSY, REAR WHEEL LH	1	Rp379.500
12	52400-77800-000 SUB: 52400-77800L000	.PISTON CUP/BOOT SET	2	Rp39.000
13	53441-80050-000	.SPRING, WHEEL CYLINDER	2	Rp29.000
14	55151-78451-000 SUB: 52473-83040-000	.PLUG, BLEEDER LH	1	Rp45.500
15	DISCONTINUE SUB: 52474-85200-000	.CAP, BLEEDER PLUG LH	1	-
16	53741-60A00-000 SUB: 53741-60A00L000	LEVER, STOPPER	2	Rp32.500
17	53751-85200-000 SUB: 53751-85200L000	CLIP, PARKING BRAKE LEVER	2	Rp5.500
18	53810-77500-000	ROD, PARKING BRAKE RH	1	-
19	53860-77500-000	ROD, PARKING BRAKE LH	1	-
20	53821-60A00-000 SUB: 53821-60A00L000	SPRING, ROD RH	1	Rp15.500
21	53822-60A00-000 SUB: 53822-60A00L000	SPRING, ROD LH	1	Rp13.500
22	DISCONTINUE SUB: 53721-77500L000	LEVER, PARKING SHOE RH	1	-
23	DISCONTINUE SUB: 53726-77500L000	LEVER, PARKING SHOE LH	1	-
24	53731-85200-000 SUB: 53731-85200L000	PIN, PARKING LEVER	2	Rp7.500
25	09159-08075-000	NUT, REAR BRAKE	8	Rp14.000
26	53820-77500-000 SUB: 53820-77500L000	RETAINER, REAR WHEEL OUTER	2	Rp102.500
27	DISCONTINUE SUB: 53610-77500L000	ANCHOR ASSY	2	-
28	DISCONTINUE SUB: 53742-77500L000	WASHER, ANCHOR	4	-
29	53743-77500-000	BOLT, ANCHOR	4	-
