FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.38 FRONT SUSPENSIONFIG.39 FRONT SUSPENSION FRAMEFIG.40 FRONT AXLEFIG.41 REAR SUSPENSIONFIG.42 REAR AXLEFIG.43 WHEEL AND TIREFIG.44 STEERING WHEELFIG.45 STEERING SHAFTFIG.46 STEERING GEARFIG.47 STEERING LINKFIG.48 PEDAL AND PEDAL BRACKETFIG.49 BRAKE MASTER CYLINDERFIG.50 BRAKE RESERVOIRFIG.51 BRAKE PIPINGFIG.52 FRONT WHEEL BRAKEFIG.53 REAR WHEEL BRAKEFIG.54 PARKING BRAKEFIG.55 SUSPENSION BRACKET

FIG.39 FRONT SUSPENSION FRAME

FIG.39 FRONT SUSPENSION FRAME
No No. Part Description Qty Price Per Pcs Remarks
1 71110-77501-000 FRAME, FRONT SUSPENSION 1 Rp4.690.000
2 09118-12002-000 BOLT (12X20) 4 Rp34.000
3 45200-77510-000
SUB: 45200-77500-000		 ARM ASSY, FRONT SUSPENSION 2 Rp695.500
4 DISCONTINUE
SUB: 45721-79010-000		 .SEAL, BALL JOINT DUST 2 -
5 09401-30401-000 .CLIP, DUST SEAL 2 Rp20.500
6 09319-12045-000 .BUSHING 2 Rp355.500
7 09103-12048-000 BOLT (12X93) 2 Rp56.000
8 DISCONTINUE
SUB: 08321-01123L000		 LOCK WASHER 2 -
9 08314-40123-000
SUB: 08314-40123L000		 NUT 2 Rp4.500
10 04111-3020A-000
SUB: 04111B3020AN000		 PIN 2 Rp2.500
11 45310-77500-000
SUB: 45310B77500N000		 ROD, TENSION 2 Rp145.000
12 09119-10040-000 BOLT (10X25) 4 Rp16.500
13 08321-0110A-000 LOCK WASHER 4 Rp14.000
14 08310-0010A-000
SUB: 08310B0010AN000		 NUT 4 Rp3.500
15 45341-77500-000 BUSHING, TENSION ROD 4 Rp113.500
16 45313-77500-000 WASHER, TENSION ROD 2 Rp67.000
17 09159-12017-000
SUB: 09159B12017N000		 NUT 2 Rp14.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
