FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.38 FRONT SUSPENSIONFIG.39 FRONT SUSPENSION FRAMEFIG.40 FRONT AXLEFIG.41 REAR SUSPENSIONFIG.42 REAR AXLEFIG.43 WHEEL AND TIREFIG.44 STEERING WHEELFIG.45 STEERING SHAFTFIG.46 STEERING GEARFIG.47 STEERING LINKFIG.48 PEDAL AND PEDAL BRACKETFIG.49 BRAKE MASTER CYLINDERFIG.50 BRAKE RESERVOIRFIG.51 BRAKE PIPINGFIG.52 FRONT WHEEL BRAKEFIG.53 REAR WHEEL BRAKEFIG.54 PARKING BRAKEFIG.55 SUSPENSION BRACKET

FIG.45 STEERING SHAFT

FIG.45 STEERING SHAFT
No No. Part Description Qty Price Per Pcs Remarks
1 48310-77500-000
SUB: 48310-77500L000		 COLUMN, STEERING 1 Rp139.500
2 01550-0812A-000
SUB: 01550B0812AN000		 BOLT 4 Rp3.500
3 48381-51041-000 BUSH 2 Rp66.000
4 48400-77500-5PK
SUB: 48400-77500L5PK		 COVER ASSY, COLUMN (BLACK) 1 Rp143.500
5 02142-0508A-000
SUB: 02142B0508AN000		 SCREW 1 Rp3.500
6 09136M05030-000 SCREW 2 Rp4.500
7 03211-0516A-000 SCREW 4 Rp13.000
8 48211-77500-000
SUB: 48211-77500L000		 SHAFT, STEERING UPPER 1 Rp42.500
9 48220-77500-000
SUB: 48220-77500L000		 SHAFT, STEERING LOWER 1 Rp47.500
10 48230-85000-000 JOINT, STEERING 1 Rp793.500
11 09117-08053-000 BOLT (8X30) 2 Rp27.000
12 08316-1012A-000
SUB: 08316B1012AN000		 NUT 1 Rp6.500
13 09160-17501-XC0
SUB: 09160-17501-000		 WASHER (17.5X34X2) 2 Rp20.500
14 08331-31179-000
SUB: 08331-3117A-000		 CIRCLIP 2 Rp12.500
15 48491-85000-000 RUBBER, STEERING SHAFT SEAL 1 Rp35.500
16 48250-79000-000 JOINT, RUBBER 1 Rp216.000
17 01500-0830A-000 BOLT 4 -
18 08321M01083-000
SUB: 08321M0108A-000		 LOCK WASHER 4 Rp11.000
19 08310-0008A-000
SUB: 08310M0008A-000		 NUT 4 Rp12.500
20 48270-85000-000 FLANGE, RUBBER JOINT 1 Rp161.500
21 09117-08053-000 BOLT (8X30) 1 Rp27.000
22 48262-58001-000 PLATE, RUBBER JOINT 2 Rp29.500
23 48281-77500-000 SPRING 1 -
24 48291-85000-000 COVER, STEERING JOINT 1 Rp66.000
25 02142-0508A-000
SUB: 02142B0508AN000		 SCREW 1 Rp3.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
