FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.38 FRONT SUSPENSIONFIG.39 FRONT SUSPENSION FRAMEFIG.40 FRONT AXLEFIG.41 REAR SUSPENSIONFIG.42 REAR AXLEFIG.43 WHEEL AND TIREFIG.44 STEERING WHEELFIG.45 STEERING SHAFTFIG.46 STEERING GEARFIG.47 STEERING LINKFIG.48 PEDAL AND PEDAL BRACKETFIG.49 BRAKE MASTER CYLINDERFIG.50 BRAKE RESERVOIRFIG.51 BRAKE PIPINGFIG.52 FRONT WHEEL BRAKEFIG.53 REAR WHEEL BRAKEFIG.54 PARKING BRAKEFIG.55 SUSPENSION BRACKET

FIG.42 REAR AXLE

FIG.42 REAR AXLE
No No. Part Description Qty Price Per Pcs Remarks
1 43511-77500-000
SUB: 43511-77500L000		 DRUM, BRAKE REAR 2 Rp511.000
2 44210-775M0-000
SUB: 44210-775M0L000		 SHAFT, REAR AXLE 2 Rp1.281.000
3 09119-12012-000 BOLT, REAR HUB 8 Rp14.500
4 43460-775M0-000 BEARING, REAR WHEEL 2 Rp415.500
5 43470-775M0-000 OIL SEAL 2 Rp79.000
6 43485-775M0-000 RING, BEARING RETAINER 2 Rp256.500
7 DISCONTINUE
SUB: 46510-775M0L000		 HOUSING ASSY, REAR AXLE 1 -
8 46563-775M0-000 .STUD BOLT, AXLE HOUSING 2 Rp19.000
9 46564-775M0-000 .BOLT, AXLE HOUSING 8 Rp17.500
10 46542-775M0-000 PLUG, BREATHER 1 Rp105.500
11 46550-775M0-000 PLUG, DRAIN 1 Rp75.000
12 46562-775M0-000 .GASKET, DRAIN PLUG 1 Rp21.000
13 46551-775M0-000 PLUG, OIL LEVEL 1 Rp39.500
14 46561-775M0-000 .GASKET, OIL LEVEL PLUG 1 Rp12.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
