FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.38 FRONT SUSPENSIONFIG.39 FRONT SUSPENSION FRAMEFIG.40 FRONT AXLEFIG.41 REAR SUSPENSIONFIG.42 REAR AXLEFIG.43 WHEEL AND TIREFIG.44 STEERING WHEELFIG.45 STEERING SHAFTFIG.46 STEERING GEARFIG.47 STEERING LINKFIG.48 PEDAL AND PEDAL BRACKETFIG.49 BRAKE MASTER CYLINDERFIG.50 BRAKE RESERVOIRFIG.51 BRAKE PIPINGFIG.52 FRONT WHEEL BRAKEFIG.53 REAR WHEEL BRAKEFIG.54 PARKING BRAKEFIG.55 SUSPENSION BRACKET

FIG.38 FRONT SUSPENSION

FIG.38 FRONT SUSPENSION
No No. Part Description Qty Price Per Pcs Remarks
1 45111-77510-000
SUB: 45111-77500-000		 KNUCKLE, STEERING RH 1 Rp414.000
2 45151-77510-000
SUB: 45151-77500-000		 KNUCKLE, STEERING LH 1 Rp414.000
3-1 DISCONTINUE
SUB: 41601-77501L000		 STRUT ASSY, RH (SHOWA) 1 -
3-2 41601-77511-000
SUB: 41601-77511L000		 STRUT ASSY, RH (KAYABA) 1 Rp870.500
4-1 DISCONTINUE
SUB: 41602-77501L000		 STRUT ASSY, LH (SHOWA) 1 -
4-2 41602-77511-000
SUB: 41602-77511L000		 STRUT ASSY, LH (KAYABA) 1 Rp870.500
5 09103M12051-000
SUB: 09103M12501-000		 BOLT (12X55) 4 Rp10.500
6 DISCONTINUE
SUB: 08321-01123L000		 WASHER 4 -
7 08310-0012A-000
SUB: 08310-00123L000		 NUT 4 Rp17.500
8 41724-85000-000
SUB: 41724-85000L000		 CAP, STRUT SUPPORT 2 Rp9.500
9 08310-0014A-000 NUT 2 Rp19.500
10 08321-0114A-000 LOCK WASHER 2 Rp16.500
11 08322-0114A-000 WASHER 2 Rp14.000
12 41723-85000-000
SUB: 41723-85000L000		 STOPPER 2 Rp47.000
13 41710-61J01-000
SUB: 41710-61J00-000		 SUPPORT, FRONT STRUT 2 Rp110.500
14 09159-08140-000 NUT 6 Rp20.000
15 41721-85010-000
SUB: 41721-77500-000		 RUBBER, STRUT SUPPORT 2 Rp97.500
16 41741-77500-000
SUB: 41741-77500L000		 SEAT, BEARING 2 Rp48.000
17 41742-60G00-000 BEARING, FRONT STRUT 2 Rp159.000
18 41230-77500-000
SUB: 41230-77500L000		 SEAT, SPRING UPPER 2 Rp107.500
19 41211-77500-000
SUB: 41211-77500L000		 SEAT, SPRING 2 Rp70.500
20 42111-85400-000
SUB: 42111-85400L000		 STOPPER, FRONT BUMP 2 Rp29.000
21 41111-77500-000
SUB: 41111-77510L000		 SPRING, FRONT COIL 2 Rp393.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
