FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.38 FRONT SUSPENSIONFIG.39 FRONT SUSPENSION FRAMEFIG.40 FRONT AXLEFIG.41 REAR SUSPENSIONFIG.42 REAR AXLEFIG.43 WHEEL AND TIREFIG.44 STEERING WHEELFIG.45 STEERING SHAFTFIG.46 STEERING GEARFIG.47 STEERING LINKFIG.48 PEDAL AND PEDAL BRACKETFIG.49 BRAKE MASTER CYLINDERFIG.50 BRAKE RESERVOIRFIG.51 BRAKE PIPINGFIG.52 FRONT WHEEL BRAKEFIG.53 REAR WHEEL BRAKEFIG.54 PARKING BRAKEFIG.55 SUSPENSION BRACKET

FIG.52 FRONT WHEEL BRAKE

FIG.52 FRONT WHEEL BRAKE
No No. Part Description Qty Price Per Pcs Remarks
1 DISCONTINUE
SUB: 55101B77502N000		 CARIPER ASSY, RH 1 -
2 DISCONTINUE
SUB: 55102B77502N000		 CARIPER ASSY, LH 1 -
3 55191-77500-000
SUB: 55191-77500L000		 .PIN A 2 Rp38.500
4 55192-77500-000
SUB: 55192-77500L000		 .PIN B 2 Rp63.500
5 55206-77300-000
SUB: 55206-77300L000		 .BOLT, PIN 4 Rp8.500
6 55200-77502-000
SUB: 55200B77502N000		 .PAD SET, DISC BRAKE 1 Rp158.000
7 55135-77500-000
SUB: 55135-77500L000		 .PLATE, PAD SUPPORT 4 Rp21.500
8 55234-77500-000
SUB: 55234-77500L000		 .SPRING, PAD 2 Rp34.000
9 55173-77300-000
SUB: 55173-77300L000		 .PLUG, BLEEDER 2 Rp32.500
10 DISCONTINUE
SUB: 52474-85200-000		 .CAP, BLEEDER 2 -
11 55100-77810-000
SUB: 55100-77810L000		 .PISTON/CUP SET 2 Rp247.000
12 55136-77300-000
SUB: 55136-77300L000		 ..SEAL, PISTON 2 Rp37.500
13 55141-77300-000
SUB: 55141-77300L000		 ..BOOT, PISTON 2 Rp32.000
14 55201-77300-000
SUB: 55201-77300L000		 .BOOT, PISTON 4 Rp16.000
15 09100-12064-000 BOLT (12X30) 4 Rp35.500
16 DISCONTINUE
SUB: 08321-01123L000		 LOCK WASHER 4 -
17 55211-77500-000
SUB: 55211-77500L000		 DISC, FRONT BRAKE 2 Rp350.000
18 09117-10042-000 BOLT, BRAKE DISC (10X25) 8 Rp22.000
19 55221-77500-000
SUB: 55221B77500N000		 COVER, BRAKE RH 1 Rp31.500
20 55222-77500-000
SUB: 55222B77500N000		 COVER, BRAKE LH 1 Rp31.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
