FIG.21A EMISSION CONTROL (TYPE 3)

FIG.21A EMISSION CONTROL (TYPE 3)
No No. Part Description Qty Price Per Pcs Remarks
1 18114-58M00-000 VALVE ASSY, DUTY FOR PURGE 1 Rp887.500
2 18417-71P00-000 BRACKET,VSV 1 Rp9.000
3 18564-59R00-000 HOSE, PURGE (VSV TO INMF) 1 Rp31.000
4 09401-10409-000
SUB: 09401-11419-000		 CLIP 2 Rp7.500
5 01550-0616A-000
SUB: 01550B0616AN000		 BOLT 1 Rp3.500
6 08316-1006A-000
SUB: 08316B1006AN000		 NUT 1 Rp2.000
7 18351-77M00-000
SUB: 18351B77M00N000		 PIPE, PURGE (RH) 1 Rp130.000
8 18560-59R00-000 CANISTER 1 Rp260.000
9 18561-59R00-000 HOSE, CANISTER INLET 1 Rp24.500
10 18562-59R00-000 HOSE, PURGE (CSTR TO VSV) 1 Rp55.000
11 18567-77M00-000
SUB: 18567B77M00N000		 HOSE, PURGE AIR SUCTION 1 Rp46.500
12 18570-74L10-000
SUB: 18570B74L10N000		 BRACKET, CANISTER (RH) 1 Rp17.000
13 09159-06076-000 NUT (M6) 2 Rp19.500
14 09401-10409-000
SUB: 09401-11419-000		 CLIP 6 Rp7.500
15 09408-00304-000 CLAMP 1 Rp43.000
16 18590-67LA0-000
SUB: 18590B67LA0N000		 SENSOR, MAP 1 Rp244.000
17 01550-0620C-000 BOLT 1 Rp5.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
