FIG. 483A UNDER COWLING

No	No. Part	Description	Qty	Price Per Pcs
1-2	68183-20L00-JSP	EMBLEM,SIDE COVER NO.1,R (BLACK,RED)	1	Rp7.500
1-1	68183-20L00-CDZ	EMBLEM,SIDE COVER NO.1,R	1	Rp7.500
1-3	68183-20L00-CC7	EMBLEM,SIDE COVER NO.1,R (ORANGE,BLACK)	1	Rp7.500
2-1	68184-20L00-CD1	EMBLEM,SIDE COVER NO.2,R	1	Rp11.500
2-2	68184-20L00-AA3	EMBLEM,SIDE COVER NO.2,R (GRAY,BLACK)	1	Rp11.500
2-3	68184-20L00-CD2	EMBLEM,SIDE COVER NO.2,R	1	Rp11.500
3-1	68185-20L00-CDT	TAPE,SIDE COVER,R	1	Rp28.500
3-2	68185-20L00-CDU	TAPE,SIDE COVER,R	1	Rp28.500
3-3	68185-20L00-CDV	TAPE,SIDE COVER,R	1	Rp28.500
4-1	68193-20L00-CDZ	EMBLEM,SIDE COVER NO.1,L	1	Rp7.500
4-2	68193-20L00-JSP	EMBLEM,SIDE COVER NO.1,L (BLACK,RED)	1	Rp7.500
4-3	68193-20L00-CC7	EMBLEM,SIDE COVER NO.1,L (ORANGE,BLACK)	1	Rp7.500
5-1	68194-20L00-CD1	EMBLEM,SIDE COVER NO.2,L	1	Rp11.500
5-3	68194-20L00-CD2	EMBLEM,SIDE COVER NO.2,L	1	Rp11.500
5-2	68194-20L00-AA3	EMBLEM,SIDE COVER NO.2,L (GRAY,BLACK)	1	Rp11.500
6-1	68195-20L00-CDT	TAPE,SIDE COVER,L	1	Rp28.500
6-2	68195-20L00-CDU	TAPE,SIDE COVER,L	1	Rp28.500
6-3	68195-20L00-CDV	TAPE,SIDE COVER,L	1	Rp28.500
7	47315-41K00-000	CUSHION (8-14X26-32X7)	2	Rp6.500
8	94413-20L00-000	COWLING,BODY CTR	1	Rp22.500
9-3	94441-20L00-QVN	COVER,SIDE,R (ORANGE)	1	Rp295.500
9-2	94441-20L00-YVB	COVER,SIDE,R (BLACK)	1	Rp295.500
9-1	94441-20L00-YU1	COVER,SIDE,R (YELLOW)	1	Rp295.500
10	94442-20L00-000	COVER,SIDE INNER,R	1	Rp65.500
11-1	94451-20L00-YU1	COVER,SIDE,L (YELLOW)	1	Rp295.500
11-2	94451-20L00-YVB	COVER,SIDE,L (BLACK)	1	Rp295.500
11-3	94451-20L00-QVN	COVER,SIDE,L (ORANGE)	1	Rp295.500
12	94452-20L00-000	COVER,SIDE INNER,L	1	Rp65.500
13	94491-20L00-000	COWLING,INNER CTR	1	Rp84.000
14	94530-20L00-000	BRACKET,SIDE COWL,R	1	Rp47.000
15	94540-20L00-000	BRACKET,SIDE COWL,L	1	Rp47.000
16	09111-06072-000	BOLT (6X17.8)	2	Rp3.500
17	09111-06102-000	BOLT (6X14.8)	2	Rp3.500
18	09139-05091-000	SCREW (5X13)	2	Rp68.000
19	48169-12JA0-000 SUB: 09320-08018-000	CUSHION (8X26X7)	6	Rp15.000
20	09409-06L07-000	CLIP	8	Rp10.000
21	09409-06346-000	CLIP	8	Rp3.500
22	09409-08L09-000	CLIP	4	Rp8.500
23	09409-08014-000	CLIP	4	Rp3.000
24	01550-0616A-000	BOLT	2	Rp3.500
25	01550-0616B-000	BOLT	2	Rp5.500
26	03541-0516A-000	SCREW	2	Rp3.500
