FIG. 17 KICK STARTER

No	No. Part	Description	Qty	Price Per Pcs
1	25211-22J00-000 SUB: 25211B22J00N000	FORK, GEAR SHIFT NO.1	1	Rp61.500
2	25221-22J00-000 SUB: 25221B22J00N000	FORK, GEAR SHIFT NO.2	1	Rp61.500
3	25411-22J00-000 SUB: 25411B22J00N000	SHAFT, GEAR SHIFT FORK NO.1	1	Rp14.000
4	25421-22J00-000 SUB: 25421B22J00N000	SHAFT, GEAR SHIFT FORK NO.2	1	Rp78.500
5	25311-23F80-000 SUB: 25311B23F80N000	CAM, GEAR SHIFT	1	Rp111.000
6	25381-22J00-000 SUB: 25381B22J00N000	PLATE, SHIFT CAM STOPPER	1	Rp76.500
7	25390-22J00-000 SUB: 25390B22J00N000	PLATE, GEAR SHIFT CAM	1	Rp65.000
8	09261-03002-000 SUB: 09261B03002N000	PIN (3X9.8)	2	Rp2.500
9	01500-0630A-000 SUB: 01500B0630AN000	BOLT	1	Rp4.000
10	09160-06012-000 SUB: 09160B06012N000	WASHER (6.5X22X1.6)	1	Rp7.000
11	DISCONTINUE SUB: 25350B22J00N000	STOPPER, GEAR SHIFT CAM	1	-
12	25355-22J01-000 SUB: 25355B22J00N000	SPRING, SHIFT CAM STOPPER	1	Rp5.000
13	25357-22J00-000 SUB: 25357B22J00N000	BOLT, SHIFT CAM STOPPER	1	Rp4.000
14	08211-06121-000 SUB: 08211B06121N000	WASHER	1	Rp7.500
15	25520-22J00-000 SUB: 25520B22J00N000	ARM, GEAR SHIFT	1	Rp37.500
16	25527-22J00-000 SUB: 25527B22J00N000	SPRING GEAR SHIFT PAWL	1	Rp23.500
17	25518-22J00-000 SUB: 25518B22J00N000	SPRING GEAR SHIFT ARM RETURN	1	Rp13.000
18	25510-22J00-000 SUB: 25510B22J00N000	SHAFT, GEAR SHIFT	1	Rp53.500
19	25671-22J00-000 SUB: 25671B22J00N000	STOPPER, GEAR SHIFT ARM	1	Rp8.000
20	09180-06367-000 SUB: 09180B06367N000	SPACER	1	Rp4.500
21	09283-12010-000 SUB: 09285B12006N000	OIL SEAL (12X22X9)	1	Rp10.000
22	25610-22J00-000 SUB: 25610B22J00N000	LEVER, GEAR SHIFT	1	Rp68.000
23	01500-0820A-000 SUB: 01500B0820AN000	BOLT	1	Rp5.500
24	37720-22J00-000 SUB: 37720B22J00N000	BASE ASSY, GEAR SHIFT TERM	1	Rp33.000
25	09209-05011-000 SUB: 09209B05011N000	PIN (5X15.5)	1	Rp5.500
26	09280-21008-000 SUB: 09280-21008L000	O RING (D:2.5,ID:21)	1	Rp2.500
27	09440-04010-000 SUB: 09440B04010N000	SPRING	1	Rp3.000
28	02142-0620A-000 SUB: 02142B0620AN000	SCREW	1	Rp5.500
29	23200-22J00-000 SUB: 23200B22J00N000	GUIDE ASSY, CLUTCH RELEASE	1	Rp77.500
30	23223-22J00-000 SUB: 23223B22J00N000	.BOLT, CLUTCH RELEASE ADJUST	1	Rp26.000
31	23230-22J00-000 SUB: 23230B22J00N000	.GUIDE COMP,CL RLSE BALL INNER	1	Rp37.000
32	23240-22J00-000 SUB: 23240B22J00N000	.GUIDE, CL RLSE BALL OUTER	1	Rp36.000
33	23250-22J00-000 SUB: 23250B22J00N000	.BALL, CLUTCH RELEASE	1	Rp9.000
34	09280-08005-000 SUB: 09280B08005N000	.O-RING (D:1.7,ID:7.7)	1	Rp2.000
35	09140-12051-000 SUB: 09140B12051N000	NUT	1	Rp10.000
36	09280-12004-000 SUB: 09280B12004N000	O RING (D:1.9,ID:11.8)	1	Rp2.500
37	23220-22J00-000 SUB: 23220B22J00N000	ARM,CLUTCH RELEASE	1	Rp147.000
