FIG. 15 TRANSMISSION

No	No. Part	Description	Qty	Price Per Pcs
1	21110-22J20-000 SUB: 21110B22J00N000	GEAR PRIMARY DRIVE (NT:21)	1	Rp313.500
2	21631-22J00-000 SUB: 21631B22J00N000	RACE, ONE WAY CLUTCH INNER	1	Rp56.000
3	21652-23F00-000 SUB: 21652B23F00N000	RETAINER, ONE WAY CLUTCH	2	Rp8.500
4	09261-07006-000 SUB: 09261B07006N000	ROLLER (7X10)	3	Rp4.000
5	21653-22J01-000 SUB: 21653B22J00N000	SPRING	3	Rp4.000
6	21200-22J00-000 SUB: 21200B22J00N000	GEAR ASSY, PRIMARY DRIVEN (NT:69)	1	Rp97.500
7	21251-22J00-000 SUB: 21251B22J00N000	SPACER, PRIMARY DRIVEN GEAR	1	Rp41.000
8	21411-22J00-000 SUB: 21411B22J00N000	HUB, CLUTCH SLEEVE	1	Rp60.000
9	21441-22J00-000 SUB: 21441B22J00N000	PLATE, CLUTCH DRIVE NO.1	2	Rp72.500
10	21442-22J00-000 SUB: 21442B22J00N000	PLATE, CLUTCH DRIVE NO.2	1	Rp41.500
11	21451-22J00-000 SUB: 21451B22J00N000	PLATE, CLUTCH DRIVEN	2	Rp23.500
12	21461-22J00-000 SUB: 21461B22J00N000	DISC, CLUTCH PRESSURE	1	Rp41.500
13	21465-22J00-000 SUB: 21465B22J00N000	PLATE, RELEASE	1	Rp21.000
14	21472-22J00-000 SUB: 21472B22J00N000	SPRING, CLUTCH	1	Rp21.500
15	21471-22J00-000 SUB: 21471B22J00N000	SEAT, CLUTCH SPRING	1	Rp7.500
16	21412-22J00-000 SUB: 21412B22J00N000	BOLT, CLUTCH SPRING	4	Rp3.000
17	09140-14022-000 SUB: 09140B14022N000	NUT	1	Rp9.000
18	09160-14016-000	WASHER (14X29X0.8)	1	Rp12.000
19	09164-14011-000 SUB: 09164B14011N000	WASHER (14X21X1.4)	1	Rp4.000
20	DISCONTINUE SUB: 21212B22J00N000	SPACER, PRIMARY DRIVE GEAR	1	-
21	21501-22J00-000 SUB: 21501B22J00N000	CLUTCH ASSY, SHOE	1	Rp187.500
22	09140-14022-000 SUB: 09140B14022N000	NUT	1	Rp9.000
23	09160-14016-000	WASHER (14X29X0.8)	1	Rp12.000
24	09164-14011-000 SUB: 09164B14011N000	WASHER (14X21X1.4)	1	Rp4.000
25	08110-60020-000 SUB: 08110B60020N000	BEARING	1	Rp43.000
