BALENO AK414

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.400A FRONT SUSPENSIONFIG.408A FRONT STABILIZERFIG.410A FRONT DRIVE SHAFT (5MT)FIG.410B FRONT DRIVE SHAFT (4AT)FIG.418A FRONT SUSPENSION FRAMEFIG.430A REAR SUSPENSIONFIG.449A ROAD WHEEL/TIREFIG.451A STEERING WHEELFIG.453A STEERING COLUMNFIG.480A STEERING UNITFIG.490A PEDAL/PEDAL BRACKET (5MT)FIG.490B PEDAL/PEDAL BRACKET (4AT)FIG.500A BRAKE MASTER CYLINDER (5MT)FIG.500B BRAKE MASTER CYLINDER (4AT)FIG.503A BRAKE PIPINGFIG.510A ANTI LOCK BRAKE SYSTEMFIG.520A FRONT WHEEL BRAKEFIG.530A REAR WHEEL BRAKEFIG.542A PARKING BRAKE

FIG.490B PEDAL/PEDAL BRACKET (4AT)

FIG.490B PEDAL/PEDAL BRACKET (4AT)
No No. Part Description Qty Price Per Pcs Remarks
1 49400M68P00-000 PEDAL ASSY, ACCELERATOR 1 Rp784.000
2 09159-08127-000
SUB: 09159M08153-000		 NUT 2 Rp11.000
3 49600M68P10-000 PEDAL ASSY, BRAKE 1 Rp554.000
4 49751M50M10-000 •PAD, PEDAL 1 Rp24.000
5 09159-08127-000
SUB: 09159M08153-000		 NUT 1 Rp11.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
