Suzuki Nex Fi

Preview Engine Transmission Electrical Suspension Body

< KEMBALI KE THUMBNAIL FIG. 1 CYLINDER HEAD COVER FIG. 2 CYLINDER HEAD FIG. 3 CYLINDER FIG. 4 CRANKCASE FIG. 5 CRANKCASE COVER FIG. 6 CRANKSHAFT FIG. 7 CAMSHAFT/VALVE FIG. 8 CAM CHAIN FIG. 9 THROTTLE BODY FIG. 10 AIR CLEANER FIG. 11 MUFFLER FIG. 12 OIL PUMP FIG. 13 FUEL PUMP FIG. 14 COOLING FAN FIG. 15 TRANSMISSION FIG. 16 TRANSMISSION (2)FIG. 17 KICK STARTER

FIG. 9 THROTTLE BODY

FIG. 9 THROTTLE BODY

No	No. Part	Description	Qty	Price Per Pcs	Remarks
1	13400-09JA3-000 SUB: 13400B09JA0N000	BODY ASSY THROTTLE (AC22-4 )	1	Rp862.000
2	13295-16HA0-000	O RING (616-66001)	1	Rp5.000
3	13417-09JA0-000	COMPRESSION SPRING (730-09091)	1	Rp9.500
4	13421-09JA0-000	PLATE (E402013-1A)	1	Rp28.500
5	13602-06128-000	SCREW (C2-0612)	1	Rp9.000
6	18117-09JA0-000	STEPPING MOTOR (SE ST10-TY34-999)	1	Rp262.500
7	13438-09JA0-000	O RING (ST50/04)	1	Rp27.500
8	15710-09JB0-000	INJECTOR ASSY FUEL (SM297500-20503S)	1	Rp252.000
9	15720-09300-000	GROMMET (195585-0010)	2	Rp11.500
10	15710-09300-000	O RING (195586-0530)	2	Rp13.500
11	15715-16HC0-000	INSULATOR FUEL INJECTOR	2	Rp36.000
12	13111-09JA1-000 SUB: 13111B09JA0N000	PIPE INTAKE	1	Rp67.000
13	15830-09JA0-000	JOINT COMP FUEL HOSE	1	Rp131.000
14	01547-0620B-000 SUB: 01547-0620A-000	BOLT	1	Rp6.500
15	01547-0625A-000	BOLT	1	Rp6.500
16	01547-0640B-000 SUB: 01547-0640A-000	BOLT	1	Rp7.000
17	09280-26011-000	O RING(D:2.4 ID:25.7)	1	Rp8.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
