FIG. 524A STEERING STEM

FIG. 524A STEERING STEM
No No. Part Description Qty Price Per Pcs Remarks
1 51166-41H00-000 BOLT 4 Rp7.500
2 51410-09J00-000 BRACKET FORK,UNDER 1 Rp538.500
3 51622-41H00-000 .RACE 1 Rp56.500
4 51611-41H01-000 RACE,STEERING INNER UPPER 1 Rp20.500
5 51612-41H01-000 RACE,STEERING INNER LOWER 1 Rp20.500
6 51621-41H00-000 RACE,STEERING OUTER UPPER 1 Rp31.000
7 51631-05000-000 NUT,STEERING STEM 1 Rp20.000
8 51631-05000-000 NUT,STEERING STEM 1 Rp20.000
9 51643-06001-000 DUST SEAL,UPPER 1 Rp3.000
10 51645-41H00-000 CUSHION,DUST COVER LOWER 1 Rp3.000
11 09166-24001-000 WASHER (24.5X34X2.3) 1 Rp4.500
12 06111-06004-000 BALL 23 Rp1.000
13 06111-06004-000 BALL 28 Rp1.000
14 51331-49K00-000 HOLDER,HANDLE UPPER 2 Rp93.000
15 51332-49K00-000 HOLDER,HANDLE LOWER 2 Rp111.000
16 51358-09G00-000 STOPPER,HANDLEBAR 1 Rp8.000
17 51680-49K00-000 PLATE,STEERING SHAFT 1 Rp128.000
18 09100-10326-000 BOLT,HANDLE HOLDER LOWER 2 Rp6.500
19 09103-08573-000 BOLT,HANDLE HOLDER UPPER 4 Rp5.000
20 09103-10126-000 BOLT (10X48) 1 Rp28.500
21 08319-3110A-000 NUT 2 Rp4.500
22 08319-3110A-000 NUT 1 Rp4.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
