New Jimny 5 Doors

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG. 072 FRONT SUSPENSIONFIG. 073 FRONT STABILIZERFIG. 074 FRONT AXLE(RHD)FIG. 075 WHEEL HUB PIPINGFIG. 076 REAR SUSPENSIONFIG. 077 AXLE HOUSING(RHD)FIG. 078 REAR AXLEFIG. 079 ROAD WHEEL/TIRE (W_ALM_WL:N/TPMS)FIG. 080 STEERING WHEEL(W/CRUISE:N/SPEED LIMITER)FIG. 081 STEERING COLUMN(RHD)FIG. 082 STEERING UNIT (RHD)FIG. 083 PEDAL/PEDAL BRACKET (RHD:5MT)FIG. 084 PEDAL/PEDAL BRACKET (RHD:4AT)FIG. 085 BRAKE MASTER CYLINDER (RHD)FIG. 086 FRONT BRAKE PIPING (RHD)FIG. 087 REAR BRAKE PIPINGFIG. 088 ANTI LOCK BRAKE SYSTEMFIG. 089 FRONT WHEEL BRAKEFIG. 090 REAR WHEEL BRAKEFIG. 091 PARKING BRAKE

FIG. 085 BRAKE MASTER CYLINDER (RHD)

FIG. 085 BRAKE MASTER CYLINDER (RHD)
No No. Part Description Qty Price Per Pcs Remarks
1-2 51000M73T00-000 CYLINDER ASSY, BRAKE MASTER 1 Rp4.310.000
1-1 51000M73T10-000 CYLINDER ASSY, BRAKE MASTER 1 Rp3.832.000
2-1 51300M73T10-000 .BOOSTER ASSEMBLY,BRAKE MASTER 1 Rp2.115.500
2-2 51300M73T00-000 .BOOSTER ASSEMBLY,BRAKE MASTER 1 Rp2.675.500
3-1 51100M73T10-000 .MASTER CYLINDER ASSY 1 Rp2.064.500
3-2 51100M73T00-000 .MASTER CYLINDER ASSY 1 Rp2.064.500
4 51232M74L00-000 ..GROMMET 2 Rp37.500
5 51233M65J00-000 ..SPRING,PIN 1 Rp29.500
6 51240M67LA0-000 ..FILTER 1 Rp51.500
7 51311M68K00-000 ..O RING 1 Rp10.500
8-1 51200M73T10-000 ..RESERVOIR ASSY,BRAKE MASTER 1 Rp569.000
8-2 51200M73T00-000 ..RESERVOIR ASSY,BRAKE MASTER 1 Rp569.000
9 51220M55T00-000 ..CAP,RESERVOIR 1 Rp90.500
10 08310-0008A-000 .NUT 2 Rp12.500
11 09385M08L01-000 CLIP 1 Rp9.000
12-1 51132M79G10-000 PACKING,BRAKE MASTER CYLINDER 1 Rp5.500
12-2 51132M79G10-000 PACKING,BRAKE MASTER CYLINDER 1 Rp5.500
13 09159-08127-000 NUT 4 Rp11.000
14 51120M60M00-000 PIN,BRAKE MASTER CYLINDER 1 Rp10.500
15 51010M73T00-000 HOSE,BRAKE VACUUM INTAKE 1 Rp65.500
16 09401M15422-000 CLAMP,BRAKE VACUUM HOSE 2 Rp9.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
