FIG. 081 STEERING COLUMN(RHD)

FIG. 081 STEERING COLUMN(RHD)
No No. Part Description Qty Price Per Pcs Remarks
1 48210M80T20-000 SHAFT ASSY,STRG COLUMN UPPER 1 Rp13.421.500
2 48240M78R03-000 SHAFT ,INTERMEDIATE 1 Rp3.909.500
3 48220-78R00-000 SHAFT ASSY,STEERING LOWER 1 Rp4.207.000
4 09117-08107-000 BOLT (8X30) 2 Rp22.000
5 09159-08127-000 NUT (B:12) 2 Rp11.000
6 01551-0812A-000 BOLT 1 Rp18.500
7 08316-1008A-000 NUT 4 Rp3.500
8 08316-1012A-000 NUT 1 Rp6.500
9 48400M66R00-5PK COVER ASSY,STEERING COLUMN(BLACK) 1 Rp130.500
10 48490-78R00-000 SEAL ASSY,STEERING SHAFT 1 Rp204.500
11 48492-78R00-000 .SEAL,STEERING SHAFT 1 Rp191.500
12 79172-78R00-000 LABEL,STEERING COLUMN AIRBAG 1 Rp31.500
13 09136M05030-000 SCREW,STRG COLUMN COVER 1 Rp4.500
14 09159M06123-000 NUT,SEAL 2 Rp1.500
15 03211M0512A-000 SCREW,STRG COLUMN COVER TPG 2 Rp4.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
