FIG.310B RECTIFIER/IGNITION COIL (DF325A)

FIG.310B RECTIFIER/IGNITION COIL (DF325A)

No	No. Part	Description	Qty	Price Per Pcs	Remarks
1	32800-26J02-000 SUB: 32800-26J01-000	RECTIFIER ASSY	2	Rp2.116.000
2	32890-98L00-000	HOLDER, ELECTRIC PARTS	1	Rp177.500
3	DISCONTINUE SUB: 09116-06202-000	BOLT (6X25)	3	-
4	09160-06006-000 SUB: 09160-06084-000	WASHER (6.5X18X1.6)	1	Rp11.000
5	09169-06062-000	WASHER	4	Rp16.500
6	09320-09016-000	CUSHION	4	Rp4.000
7	01550-06257-000	BOLT	1	Rp3.500
8	01550-0625C-000	BOLT	4	Rp14.500
9	33410-98L00-000	COIL ASSY, IGNITION	6	Rp1.194.500
10	33411-98L10-000	CUSHION, IGN COIL CONNECTOR	6	Rp130.500
11	33414-98L00-000	BRACKET, IGNITION COIL	5	Rp90.500
12	01547-06127-000	BOLT	10	Rp10.500
13	01550-0620C-000	BOLT	6	Rp5.500
14	09403-12412-000	CLAMP	1	Rp19.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
