| 1-2 |
47111-10J00-YTB
SUB: 47111B10J00NYTB |
COVER FRAME RH (SUMMER RED) |
1 |
Rp122.000 |
| |
| 1-3 |
47111-10J00-YUH
SUB: 47111B10J00NYUH |
COVER FRAME RH (BRILLIANT WHITE) |
1 |
Rp122.000 |
| |
| 1-4 |
47111-10J00-YUJ
SUB: 47111B10J00NYUJ |
COVER FRAME RH (MACHO BRIGHT BLUE) |
1 |
Rp122.000 |
| |
| 1-5 |
47111-10J00-YVE
SUB: 47111B10J00NYVE |
COVER FRAME RH (MARINE BLUE) |
1 |
Rp122.000 |
| |
| 1-6 |
47111-10J00-YVU
SUB: 47111B10J00NYVU |
COVER FRAME RH (TITAN BLACK) |
1 |
Rp122.000 |
| |
| 1-1 |
47111-10J00-PZ5
SUB: 47111B10J00NPZ5 |
COVER FRAME RH (FRASH GREEN) |
1 |
Rp122.000 |
| |
| 2-1 |
47211-10J00-PZ5
SUB: 47211B10J00NPZ5 |
COVER FRAME LH (FRASH GREEN) |
1 |
Rp122.000 |
| |
| 2-2 |
47211-10J00-YTB
SUB: 47211B10J00NYTB |
COVER FRAME LH (SUMMER RED) |
1 |
Rp122.000 |
| |
| 2-3 |
47211-10J00-YUH
SUB: 47211B10J00NYUH |
COVER FRAME LH (BRILLIANT WHITE) |
1 |
Rp122.000 |
| |
| 2-4 |
47211-10J00-YUJ
SUB: 47211B10J00NYUJ |
COVER FRAME LH (MACHO BRIGHT BLUE) |
1 |
Rp122.000 |
| |
| 2-5 |
47211-10J00-YVE
SUB: 47211B10J00NYVE |
COVER FRAME LH (MARINE BLUE) |
1 |
Rp122.000 |
| |
| 2-6 |
47211-10J00-YVU
SUB: 47211B10J00NYVU |
COVER FRAME LH (TITAN BLACK) |
1 |
Rp122.000 |
| |
| 3 |
47117-10J00-000
SUB: 47117B10J00N000 |
CUSHION, FRAME COVER |
2 |
Rp3.000 |
| |
| 4 |
48169-12JA0-000
SUB: 09320B08018N000 |
CUSHION |
4 |
Rp15.000 |
| |
| 5 |
09148-05038-000
SUB: 09148B05038N000 |
NUT |
6 |
Rp4.000 |
| |
| 6 |
03541-0516A-000
SUB: 03541B0516AN000 |
SCREW |
6 |
Rp3.500 |
| |
| 7 |
47112-10J00-291
SUB: 47112B10J00N291 |
COVER FRAME FR RH (BLACK 50% GLOSS) |
1 |
Rp122.000 |
| |
| 8 |
47212-10J00-291
SUB: 47212B10J00N291 |
COVER FRAME FR LH (BLACK 50% GLOSS) |
1 |
Rp122.000 |
| |
| 9 |
03541-0516A-000
SUB: 03541B0516BN000 |
SCREW |
6 |
Rp3.500 |
| |
| 10-1 |
47311-10J00-PZ5
SUB: 47311B10J00NPZ5 |
COVER FRAME CENTER (FRASH GREEN) |
1 |
Rp40.500 |
| |
| 10-2 |
47311-10J00-YTB
SUB: 47311B10J00NYTB |
COVER FRAME CENTER (SUMMER RED) |
1 |
Rp40.500 |
| |
| 10-3 |
47311-10J00-YUH
SUB: 47311B10J00NYUH |
COVER FRAME CENTER (BRILLIANT WHITE) |
1 |
Rp40.500 |
| |
| 10-4 |
47311-10J00-YUJ
SUB: 47311B10J00NYUJ |
COVER FRAME CENTER (MACHO BRIGHT BLUE) |
1 |
Rp40.500 |
| |
| 10-5 |
47311-10J00-YVE
SUB: 47311B10J00NYVE |
COVER FRAME CENTER (MARINE BLUE) |
1 |
Rp40.500 |
| |
| 10-6 |
47311-10J00-YVU
SUB: 47311B10J00NYVU |
COVER FRAME CENTER (TITAN BLACK) |
1 |
Rp39.500 |
| |
| 11 |
47372-10J00-291
SUB: 47372B10J00N291 |
LID, MAINTENANCE |
1 |
Rp10.500 |
| |
| 12 |
03541-0512B-000
SUB: 03541B0512BN000 |
SCREW |
2 |
Rp4.000 |
| |
| 13 |
47255-10J00-000
SUB: 47255B10J00N000 |
SCREW, FRONT COVER CENTER |
1 |
Rp7.000 |
| |
| 14 |
09148-05058-000
SUB: 09148B05058N000 |
NUT |
2 |
Rp15.000 |
| |
