FIG.25 EMISSION CONTROL (TYPE 2)

FIG.25 EMISSION CONTROL (TYPE 2)
No No. Part Description Qty Price Per Pcs Remarks
1 18111-77E02-000 VALVE, EGR 1 Rp3.137.000
2 DISCONTINUE
SUB: 18117-52G00-000		 VALVE ASSY, DUTY FOR PURGE 1 -
3 18340-61J00-000 PIPE, PURGE 1 Rp43.000
4 18529M77E01-000 GASKET, EGR VALVE 1 Rp5.500
5 18530-61J00-000 PIPE, EGR 1 Rp368.500
6 18533-77E00-000 GASKET, EGR PIPE 2 Rp29.500
7 18562-61J00-000
SUB: 18562-61J10-000		 HOSE, PURGE (CSTR TO PIPE) 1 Rp23.000
8 18563-61J00-000
SUB: 18563-61J10-000		 HOSE, PURGE (PIPE TO VSV) 1 Rp10.000
9 18564-61J00-000 HOSE, PURGE (VSV TO MANF) 1 Rp28.500
10 DISCONTINUE
SUB: 09351-80902-600		 PROTECTOR 1 - L600->140
11 09355-35006-601
SUB: 09355-35754-601		 HOSE, VAC PRESS RGLTR TO MANF 1 Rp66.000 L601->200
12 09401M11419-000 CLIP 6 Rp6.000
13 01421-0616A-000
SUB: 01421B0616AN000		 STUD BOLT 2 Rp3.500
14 01550-0616A-000
SUB: 01550B0616AN000		 BOLT 2 Rp3.500
15 01550-0850A-000 BOLT 2 Rp3.500
16 02162-0612A-000 BOLT 2 Rp11.000
17 08316-1006A-000
SUB: 08316B1006AN000		 NUT 1 Rp2.000
18 08316-1006A-000
SUB: 08316B1006AN000		 NUT 2 Rp2.000
19 18560-76A31-000 CANISTER 1 Rp1.041.500
20 18561-61J10-000 HOSE, CSTR INLET 1 Rp15.000
21 18571-65H20-000
SUB: 18571B65H20N000		 CAP, CANISTER 1 Rp11.000
22 09401M11419-000 CLIP 2 Rp6.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
