FIG.16 MUFFLER (TYPE 2)

FIG.16 MUFFLER (TYPE 2)
No No. Part Description Qty Price Per Pcs Remarks
1 14111-61J10-000 MANIFOLD, EXHAUST 1 Rp684.500
2 14140-52G00-000 GASKET, EXH MANF 1 Rp171.000
3 09108-08246-000 STUD BOLT 7 Rp21.000
4 01421-0835A-000 STUD BOLT 2 Rp13.500
5 08322M0108A-000 WASHER 7 Rp5.500
6 08310-0008A-000
SUB: 08310M0008A-000		 NUT 9 Rp12.500
7 14120-76A41-000
SUB: 14120-76A40-000		 COVER, EXH MANF UPPER 1 Rp321.500
8 14130-76A40-000 COVER, EXH MANF LOWER 1 Rp450.000
9 01411-0612A-000 STUD BOLT 2 Rp11.500
10 09159-06077-000 NUT 2 Rp17.500
11 09103-06265-000
SUB: 09103-06168-000		 BOLT (6X10) 6 Rp21.500
12 11851-76A00-000
SUB: 11851B76A00N000		 HOOK, ENGINE 1 Rp12.500
13-1 14190-61J00-000 PIPE, EXHAUST 1 Rp8.753.500 MT
13-2 14190-60K20-000 PIPE, EXHAUST 1 Rp8.753.500 AT
14 14183-76A00-000 RING, SEAL 1 Rp126.500
15 14492-67D00-000 SPRING 2 Rp64.000
16 09119-10073-000
SUB: 09119-10041-000		 BOLT (10X65) 2 Rp75.000
17 14209M78020-000
SUB: 14281-60G01-000		 MOUNTING, MUFFLER 1 Rp14.500
18-1 14300-61J40-000
SUB: 14300-61J31-000		 MUFFLER 1 Rp2.055.500 GC415T
18-2 14300-61J12-000 MUFFLER 1 Rp2.034.000 GC415V:VAN,GA,BLIND VAN
18-3 14300-60K00-000 MUFFLER 1 Rp2.461.000 GC415V:GL,GLX,SGX
19 14281-79020-000
SUB: 14281B79020N000		 MOUNTING, MUFFLER 3 Rp14.000
20 14183-76A00-000 RING, SEAL 1 Rp126.500
21 14492-67D00-000 SPRING 2 Rp64.000
22 09119-10073-000
SUB: 09119-10041-000		 BOLT (10X65) 2 Rp75.000
23 14330-61J02-000 COVER, MOUNTING MUFFLER 1 Rp78.500
24 01550-0610B-000
SUB: 01550B0610AN000		 BOLT 1 Rp3.000
25 18213-61J00-000
SUB: 18213-61J01-000		 SENSOR, OXYGEN 1 Rp713.500
26 36990-25G00-000
SUB: 09407-11401-000		 CLAMP 1 Rp13.000
27 14181-61J00-000 COVER, EXH PIPE MTG 1 Rp54.500 AT
28 02142-0610A-000
SUB: 02142B0610AN000		 SCREW 2 Rp3.500 AT

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
