SX4 S-CROSS

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.64 FRONT SUSPENSIONFIG.65 FRONT STABILIZERFIG.66 FRONT DRIVE SHAFT (5MT)FIG.67 FRONT DRIVE SHAFT (6AT)FIG.68 FRONT SUSPENSION FRAMEFIG.69 REAR SUSPENSIONFIG.70 ROAD WHEEL/TIREFIG.71 STEERING WHEEL (5MT)FIG.72 STEERING WHEEL (6AT)FIG.73 STEERING COLUMNFIG.74 STEERING UNITFIG.75 PEDAL/PEDAL BRACKET (5MT)FIG.76 PEDAL/PEDAL BRACKET (6AT)FIG.77 BRAKE MASTER CYLINDERFIG.78 BRAKE PIPINGFIG.79 ANTILOCK BRAKE SYSTEMFIG.80 FRONT WHEEL BRAKEFIG.81 REAR WHEEL BRAKEFIG.82 PARKING BRAKE

FIG.76 PEDAL/PEDAL BRACKET (6AT)

FIG.76 PEDAL/PEDAL BRACKET (6AT)
No No. Part Description Qty Price Per Pcs Remarks
1 49400M74L01-000 PEDAL ASSY, ACCELERATOR 1 Rp962.500
2 08316-1006A-000
SUB: 08316B1006AN000		 NUT, ACCELERATOR PEDAL 3 Rp2.000
3 49610M65M10-000 PEDAL , BRAKE 1 Rp168.500
4 49691M65M00-000 SPRING, BRAKE PEDAL 1 Rp18.000
5 49710M61M00-000 BRACKET , BRAKE PEDAL 1 Rp158.000
6 49751M58J10-000 PAD, PEDAL 1 Rp7.500
7 09180-10121-000 SPACER, BRAKE PEDAL SHAFT 1 Rp38.500
8 09100-10226-000 BOLT 1 Rp19.500
9 09306M13004-000
SUB: 09307M13005-000		 BUSH, PEDAL BOSS 2 Rp11.500
10 08316-1010A-000
SUB: 08316B1010AN000		 NUT 1 Rp3.500
11 09159-08127-000
SUB: 09159M08153-000		 NUT 1 Rp11.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
