SX4 S-CROSS

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.64 FRONT SUSPENSIONFIG.65 FRONT STABILIZERFIG.66 FRONT DRIVE SHAFT (5MT)FIG.67 FRONT DRIVE SHAFT (6AT)FIG.68 FRONT SUSPENSION FRAMEFIG.69 REAR SUSPENSIONFIG.70 ROAD WHEEL/TIREFIG.71 STEERING WHEEL (5MT)FIG.72 STEERING WHEEL (6AT)FIG.73 STEERING COLUMNFIG.74 STEERING UNITFIG.75 PEDAL/PEDAL BRACKET (5MT)FIG.76 PEDAL/PEDAL BRACKET (6AT)FIG.77 BRAKE MASTER CYLINDERFIG.78 BRAKE PIPINGFIG.79 ANTILOCK BRAKE SYSTEMFIG.80 FRONT WHEEL BRAKEFIG.81 REAR WHEEL BRAKEFIG.82 PARKING BRAKE

FIG.72 STEERING WHEEL (6AT)

FIG.72 STEERING WHEEL (6AT)
No No. Part Description Qty Price Per Pcs Remarks
1 48110M65MJ0-GJL WHEEL S/ASSY, STEERING (BLACK/SILVER) 1 Rp5.927.500
2 37460M74L40-5PK .SWITCH ASSY, AUDIO & CRUISE (BLACK) 1 Rp1.066.500
3 37470M65M00-000 .SWITCH ASSY, GEAR SHIFT, R 1 Rp317.000
4 37470M65M10-000 .SWITCH ASSY, GEAR SHIFT, L 1 Rp317.000
5 37490M76M10-000 .SWITCH ASSY, HANDS FREE 1 Rp437.000
6 48119-54G00-000 .SCREW 3 Rp61.000
7 48150M65M10-C48 MODULE ASSY, AIRBAG (BLACK/CHROME) 1 Rp4.038.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
