FIG.952A AIR CONDITIONER

FIG.952A AIR CONDITIONER
No No. Part Description Qty Price Per Pcs Remarks
1 95141M68P00-000 V-BELT (4PK) 1 Rp157.000
2 95200M68P00-000 COMPRESSOR ASSY 1 Rp7.346.000
3 01550-0850A-000 BOLT 3 Rp3.500
4 95310M68P01-000 CONDENSER ASSY 1 Rp2.002.000
5 95811M68P00-000 .PACKING 3 Rp13.500
6 95812M68P00-000 .PACKING 2 Rp13.500
7 95813M68P00-000 .PACKING 1 Rp19.500
8 95814M68P00-000 .PACKING 1 Rp5.500
9 95815M68P00-000 .PACKING 1 Rp31.000
10 95816M68P00-000 .PACKING 1 Rp4.500
11 95817M68P00-000 .PACKING 1 Rp15.000
12 DISCONTINUE
SUB: 01550B0612AN000		 BOLT 4 -
13-2 38860M76M00-000 RELAY ASSY (INTERFACE MICROSYSTEMS) 1 Rp58.500
13-1 38860M76M00-000 RELAY ASSY (DENSO) 1 Rp58.500
14 95640M68PA0-000 SENSOR ASSY, ROOM TEMP 1 Rp391.500
15 95642-64G20-000 SENSOR, SUN LIGHT (DENSO) 1 Rp578.000
16 95710M50S01-000 HOSE, SUCTION 1 Rp642.500
17 95896-50G00-000
SUB: 95896B50G00N000		 .O RING (D:2.4,ID:13.4) 2 Rp19.000
18 95720M68P00-000 HOSE, DISCHARGE 1 Rp444.000
19 95895-50G00-000
SUB: 95895B50G00N000		 .O RING (D:2.4,ID:10.8) 2 Rp12.500
20 95731M68P00-000 PIPE, LIQUID 1 Rp1.048.000
21 95546M74L00-000 .SENSOR, PRESSURE 1 Rp675.500
22 95891-50G00-000
SUB: 95891B50G00N000		 .O RING (D:1.8,ID:6.7) 2 Rp12.500
23 95761-55K00-000
SUB: 95761B55K00N000		 .CLAMP, LIQUID PIPE 1 Rp10.500
24 09403M08331-000 CLAMP 1 Rp6.500
25 01550-0620C-000 BOLT 5 Rp5.500
26 01551-0612C-000 BOLT 1 Rp18.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
